GE Multinet 4 Instruction Manual page 273

CHAPTER C: MODBUS MEMORY MAP
Address Qty
01C8 2 Port5 - Number of dropped received packets
01CA 2 Port5 - Number of multicast frames sent
01CC 2 Port5 - Number of broadcast frames sent
01CE 2 Port5 - Number of <64 byte fragments w/ good
CRC
01D0 2 Port6 - Number of bytes received
01D2 2 Port6 - Number of bytes sent
01D4 2 Port6 - Number of frames received
01D6 2 Port6 - Number of frames sent
01D8 2 Port6 - Total bytes received
01DA 2 Port6 - Total frames received
01DC 2 Port6 - Number of broadcast frames received
01DE 2 Port6 - Number of multicast frames received
01E0 2 Port6 - Number of frames with CRC error
01E2 2 Port6 - Number of oversized frames received
01E4 2 Port6 - Number of bad fragments rcvd(<64
bytes)
01E6 2 Port6 - Number of jabber frames received
01E8 2 Port6 - Number of collisions occured
01EA 2 Port6 - Number of late collisions occured
01EC 2 Port6 - Number of 64-byte frames rcvd/sent
01EE 2 Port6 - Number of 65-127 byte frames rcvd/sent
01F0 2 Port6 - Number of 128-255 byte frames rcvd/
sent
01F2 2 Port6 - Number of 256-511 byte frames rcvd/
sent
01F4 2 Port6 - Number of 512-1023 byte frames rcvd/
sent
01F6 2 Port6 - Number of 1023-MAX byte frames rcvd/
sent
MULTINET4 MULTI-PORT SERIAL SERVER & MANAGED SWITCH – INSTRUCTION MANUAL
Description Min Max Step Unit Format
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
0 429496 1 -
7295
MODBUS MEMORY MAP
Default
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
F9 0
C–11
