CHAPTER 4: SYSTEM ADMINISTRATION
4.6

IP Tasks

4.6.1

Settings

4.6.2

ARP Table

MULTINET4 MULTI-PORT SERIAL SERVER & MANAGED SWITCH – INSTRUCTION MANUAL
Allows the user to configure the system's IP addresses.
This screen is used to configure system IP settings. The parameters are defined as follows:
Field Name
Management The VLAN associated with the configured system IP address. By
VLAN
default, the Management VLAN is set to the Default VLAN, VID 1.
Address The IP address assigned to the system
Subnet Mask The subnet mask of the system
Default Gateway Address of the router used to get to the rest of the IP network
The screen enables you to view and flush the Address Resolution Protocol (ARP) table:
FIGURE 4–53: IP: Settings
Table 4–54:
Field Value
FIGURE 4–54: IP: ARP Table
SYSTEM ADMINISTRATION
4–89
