CHAPTER 5: THE CLI AND PROTOCOL MONITOR
CMD
set
set
show
show
MULTINET4 MULTI-PORT SERIAL SERVER & MANAGED SWITCH – INSTRUCTION MANUAL
Table 5–9: Protocol Monitor Command Set
Synopsis
Where the possible values for property are:
property param
•
•
•
•
•
•
Display the current monitor configuration for the port being
monitored. This command prints all of the configured formatting
options as well as any configured filters for the port.
Description
– Specify a type of information to be
display param
displayed from among the following possible values of
param:
– The Ethernet header is parsed into
—
ethernet
fields and the payload is displayed as a raw hex
dump.
– No analysis is performed. The entire
— raw
packet is displayed as a raw hex dump
– The Ethernet header is ignored and the IP
— ip
header is parsed into fields. The payload is
displayed as a raw hex dump
– The Ethernet header is ignored and
—
ipfull
the IP header is parsed into fields. In addition, an
attempt is made to parse additional fields in the
payload based on its type.
– The Ethernet header is ignored and part of
—
tcp
the IP header is parsed into fields. In addition, TCP
fields such as sequence number,
acknowledgement number, and window size are
displayed.
format hex | ascii
causes the packet payload to be dumped in ASCII. This
is especially useful for textual protocols such as HTTP.
mode terse | verbose
display formatting so that more white-space is used.
Payloads are also automatically dumped in both hex
and ASCII format. In some cases it may make the
monitor output more readable at the expense of more
transmitted characters per packet.
framenum enabled | disabled
enabled sequence numbers are applied to each packet.
timestamp diff | none | rel
each packet.
When diff (differential) is specified The timestamp on
the current packet corresponds to how much time
elapsed between this packet and the packet before it.
When rel (relative) is specified the timestamp on the
current packet corresponds to how much time has
elapsed since the monitor was first started.
– Limits the total number of payload lines displayed
lines n
for a packet. If set to zero, the entire packet is
displayed. n can be an integer value from 0 to 10.
THE CLI AND PROTOCOL MONITOR
– In terse mode the ascii option
– Verbose mode changes the
– When this property is
– Apply a timestamp to
5–13
