A) Incoming Connection; B) Response; C) Active Startup - Lantronix Micro125 User Manual

Connect Mode Option
Modem Response Only (Verbose)

a) Incoming Connection

Incoming Connection Mode
Never Accept Incoming
Accept with active Modem
Control In
Always Accept

b) Response

Response Mode
Character Response

c) Active Startup

Active Startup Mode
No Active Startup
With Any Character
With active Modem Control
In
With a Specific Start
Character
Manual Connection
Micro125 User Guide
8: Setup Mode: Channel Configuration
7 6
Description
Rejects all external connection attempts.
Accepts external connection requests only when the Modem
Control In input is asserted. Cannot be used with Modem Mode.
Accepts any incoming connection when a connection is not
already established. Default setting.
Description
A single character is transmitted to the serial port when there is a
change in connection state:
C = connected, D = disconnected, N = host unreachable.
The IP address of the host connecting to the CoBos device will
be provided when you use verbose mode.
This option is overridden when the Active Start Modem Mode
or Active Start Host List is in effect. Default setting is Nothing
(quiet).
Description
Does not attempt to initiate a connection under any
circumstance. Default setting.
Attempts to connect when any character is received from the
serial port.
Attempts to connect when the Modem Control In input changes
from not asserted to asserted.
Attempts to connect when it receives a specific start character
from the serial port. The default start character is carriage return.
Attempts to connect when directed by a command string
received from the serial port. The first character of the command
string must be a C (ASCII 0x43), and the last character must be
either a carriage return (ASCII 0x0D) or a line feed (0x0A). No
blanks or space characters may be in the command string.
Between the first and last command string characters must be a
full or partial destination IP address and may be a destination
port number.
The IP address must be in standard decimal-dot notation and
may be a partial address, representing the least significant 1, 2,
or 3 bytes of the remote IP address. The period is required
between each pair of IP address numbers.
5 4 3 2
0 0 1 1
1 0
1 0
45
