Configuring the UDS Using Telnet or the Serial Port
address assigned (dd should be a number between 1 and 99). For example, if the IP
address is set to 0.0.0.5, the resulting DHCP name is LTX05.
If you give the unit an IP of 0.0.0.0, you then have the option to assign an 8-character
DHCP name.
Change DHCP device name (LTRX) ? (N) Y
Enter new DHCP device name : LTRXYES

Channel 1 Configuration (Serial Port Settings)

Note:
convert a binary number to a hexadecimal is to use a scientific calculator,
such as the one available in Windows. For more information, see
Hexadecimal
Select 1 from the Change Setup menu to define how the serial port responds to
network and serial
The rest of this section describes the configurable settings within the Channel
configuration menu. Current values display in parentheses.

Baudrate

The unit and attached serial device, such as a modem, must agree on a speed or
baud rate to use for the serial connection. Valid baud rates are 300, 600, 1200, 2400,
4800, 9600 (default), 19200, 38400, 57600, and 115200 bits per second.

I/F (Interface) Mode

The Interface (I/F) Mode is a bit-coded byte that you enter in hexadecimal notation.
Note:

Figure 5-4. Server Configuration Option

Some fields require entries in hexadecimal notation. A simple way to
Conversions.
communications.

Figure 5-5. Channel 1 Configuration

To look up hex values, see B: Binary to Hexadecimal.
