4
Switch View
The Copy Canvas button
Copy Canvas
The Copy Canvas Configuration window is displayed in Figure 4-23.
Figure 4-23 The Copy Canvas Configuration window
The Rem Canvas button
Rem Canvas
Save Current Canvas Configuration
The Save Current Canvas Configuration menu saves the currently configured canvas to the switch.
It uses a canvas name and a brief description to save the canvas.
To access the Save Current Canvas Configuration menu:
1. Select the Performance icon (from the Switch View)
2. Select the Actions menu
3. Select the Save Current Canvas Configurations option
The Canvas Configuration Save menu is shown in Figure 4-24.
Figure 4-24 Canvas Configuration Save Menu
4-24
Select to copy the highlighted canvas configuration from the
list to the switch flash. You will be prompted to type in the
name and description of the canvas you want to copy your
chosen graph to. For more information about this window, see
Figure 4-23.
Select to remove a highlighted canvas from the list and the
switch flash. You will be prompted with a warning that you
are going to delete the selected canvas.
Web Tools User's Guide
