QuickLoop Tab

You can use the QuickLoop tab to create and manage QuickLoops if used in conjunction with
Zoning. For information on managing the QuickLoop feature separately, see QuickLoop Tab on
page 4-50 in this document.
The QuickLoop tab is shown in Figure 3-9.
Figure 3-9
Following is a description of the fields on the QuickLoop tab.
QuickLoop Name
Create Qloop
Delete Qloop
Rename Qloop
Switch Selection List
Web Tools User's Guide
The QuickLoop tab of the Switch/Port Level Zoning menu
To modify an existing QuickLoop, select a QuickLoop name.
Click to create a new QuickLoop. A dialog displays in which you can
enter the name of the new QuickLoop. All names must be unique and
contain no spaces.
Click to delete the QuickLoop selected in the QuickLoop Name field.
Deleting a QuickLoop automatically removes it from all aliases,
zones, and zone configurations, including the associated AL_PAs.
Click to edit the name of the QuickLoop selected in the QuickLoop
Name field. A dialog displays in which you can edit the name of the
QuickLoop.
A list of the switches available to add to the QuickLoop.
