Port Config Tab
Use the Port Config tab to create and manage zone configurations. Zone configurations are used to
enable or disable a group of zones at the same time. The Port Config tab is shown in Figure 3-11.
Figure 3-11 The Port Config tab of the Switch/Port Level Zoning menu
Following is a description of the fields and buttons that appear on the Port Config tab.
Cfg Name
Create Cfg
Delete Cfg
Rename Cfg
Zone/QLoop
Selection List
Add Mem
Remove Mem
Search Mem
Web Tools User's Guide
Select an existing configuration to modify.
Click to create a new configuration. A dialog displays. Enter the name of
the new configuration. All names must be unique and contain no spaces.
Click to delete the configuration selected in the Cfg Name field.
Click to edit the name of the configuration selected in the Cfg Name field.
This field provides a list of the zones and QuickLoops available to add to
the configuration.
Click to add the switch selected in the Zone/QLoop Selection List to the
Config Members list.
Click to remove the selected member from the Config Members list.
Click to search for a Switch name, WWN, Alias, Zone, QuickLoop in the
Member Selection List based on the type of objects displayed in that list.
