Add FA Host
Add Mem
Remove Mem
Search Mem
Add Other
Add Other Host
Fabric Assist name
Ref Zone
A/D WWN
Rpl WWN
OK
Apply
Close
Clr All
Web Tools User's Guide
Click to add the selected item as a host to the Fabric Assist
name Members list. Only a domain port or a WWN can be
added as a host.
Click to add the member selected in the Member Selection List
to the Fabric Assist name Members list.
Click to remove the selected member from the Fabric Assist
name Members list.
Click to search for a Switch name, WWN, Alias, Zone,
QuickLoop, FA Zone in the Member Selection List based on
the type of objects displayed in that list.
Click to add a switch/port, WWN or a device that currently is
not part of the Fabric.
Click to add other host that currently is not part of the fabric.
This field displays a list of the members that belong to the
Fabric Assist currently selected in the FA Name field. The
name of this list depends on the name of the WWN Fabric
Assist selected. If a Fabric Assist is not selected, the name
displays as "null Members".
Click to refresh the local zoning data base copied from the
switch. This button automatically flashes red/gray if the fabric
zoning data is changed by another client.
Click to add or delete a WWN to or from all the Aliases,
Zones, FA Zones defined.
Click to replace a WWN with another one in all Aliases, Zones,
FA Zones defined.
Applies the changes to the switch and exits the window.
Click to apply all changes made including changes made on
other tabs in the view. Changes cannot be cancelled once they
are applied.
Click to exit the window without making any changes to the
switch.
Click to clear all Aliases, Zones, Configs, FA Zones locally on
the switch.
3
Fabric View
3-47
