HP StorageWorks 8B - FC Entry Switch User Manual page 48

3
Fabric View
WWN Zone
Use the WWN Zone tab to specify the members of the WWN Zone. In this window, only switches
and WWN are available to be selected as members of the zone.
The WWN Zone tab is shown in Figure 3-14.
Figure 3-14 WWN Zone tab of the WWN Level Zoning menu
Following is a description of the fields on the WWN Zone tab.
Zone Name
Create Zone
Delete Zone
Rename Zone
Member Selection List
Zone Members
3-26
Select an existing zone member to modify.
Click to create a new zone member.
Click to delete a zone member.
Click to rename a zone member.
This field displays a list of potential zone members, including
switches, ports, WWNs, and QuickLoop AL_PAs, and Fabric Assists.
This field lists the zone members selected in the Zone Name field.
The name on this list depends on the name of the selected zone
member. If a name is not selected, the name displays as "null
Members".
Web Tools User's Guide
