HP StorageWorks 8B - FC Entry Switch User Manual page 83

The Configure Threshold display changes according to the class and area selected in the
organizational tree. However, the Configure Thresholds tab always contains the following buttons:
Default
Apply
Reset
Web Tools User's Guide
Click to return settings to default values.
Click to apply the values specified in the current display. When
Apply is clicked after a change, the Alarm Mechanism dialog
displays as shown in Figure 4-9. This dialog box is used to
specify alarm delivery mechanisms by checking the
appropriate boxes.
When Email is chosen as one of the alarm delivery
mechanisms, the text fields are enabled in the "Mail Server,
"Domain Name", "Mail From" and "Mail To" information to
configure the Email Alert by Fabric Watch Daemon function. If
Email is not chosen as one of the delivery mechanisms, the text
fields are grayed out.
When RAN is chosen, changes apply to the API application,
but not regular usage.
Figure 4-9 The Alarm Mechanism dialog box
To continue, select the type of alarm you want and click Apply.
Note:
Changes made within this window will apply to all
areas within the class you are working.
Click to undo the last changes.
4
Switch View
4-11
