Following is a description of the fields on the User Admin tab:
User Name
New Password
Verify Password
OK
Apply
Close
Reset
Note:
Firmware/Configuration File Administration
Tab
Use the Firmware/Configuration File Administration tab to complete tasks such as
•
Download firmware
•
Boot the switch
•
Upload a Configuration file to the host
•
Download the configuration from a file to the switch
•
Reset the configuration to the default value
•
Select the protocol of downloading (FTP or RSH).
Web Tools User's Guide
Enter new user name or modify the existing user name.
Note:
You cannot create a new user name to one that is already
being used. Doing so will cause the following dialog box to
appear:
Enter new password or modify the existing password.
Re-enter password to verify.
Click to save the changes made to the tab and exit the Switch
Administrative view.
Click to save the changes made to this tab. Additional changes can be
made and the Apply button clicked when making changes
incrementally.
Click to exit the Switch Administration view. If changes have been
made but not committed by clicking the Apply button, a dialog box
displays to ask the user if they want to save the changes before exiting
the view.
Click to reset the tab to the last set of committed changes. If the Apply
button has not been pressed on this tab, the parameters are returned to
the original values the tab had when it was initially displayed.
A user can only log into the User Admin Tab if they have admin privileges. A user does not
gain access to the User Interface with the User ID and Password created in this tab.
