HP StorageWorks 8B - FC Entry Switch User Manual page 54

3
Fabric View
Zone/QLoop Selection List
Add Mem
Remove Mem
Search Mem
Config Members
Analyze Config
Enable Config
Disable Config
Refresh Fabric
Ref Zone
A/D WWN
Rpl WWN
OK
Apply
Close
Clr All
3-32
This field displays a list of Zone and QuickLoop members
available to add to the WWN configuration.
Click to add a member from the config members list into the
zone selection list.
Click to remove a member from the zone selection list into the
Config Member list.
Click to search for a Switch name, WWN, Alias, Zone, Qloop
in the Zone Selection List based on the type of objects
displayed in that list.
This field displays a list of the members that belong to the
WWN Configuration currently selected in the Cfg Name field.
The name of this list depends on the name of the WWN
configuration selected. If WWN configuration is not selected,
the name displays as "null Members".
Click to analyze the configuration that is selected along with its
member zones and aliases. A zoning error screen (see
Figure 3-12) appears in the event of a conflict.
If this option is checked, and the Apply button pressed, the
selected configuration would be used for zoning the fabric.
Click the Disable Config radio button to disable the selected
WWN Zone configuration.
Click to refresh the fabric view with the latest Domain/Port and
WWN changes.
Click to refresh the local zoning data base copied from the
switch. This button automatically flashes red/gray if the fabric
zoning data is changed by another client.
Click to add/delete a WWN to/from all the Aliases, Zones
defined.
Click to replace a WWN with another one in all Aliases, Zones
defined.
Applies the changes to the switch and exits the switch.
Click to apply all changes made including changes made on
other tabs in the view. Changes cannot be cancelled once they
are applied.
Click to exit the window without making any changes to the
switch.
Click to clear all Aliases, Zones, Configs locally on the switch.
Web Tools User's Guide
