Switch View
Figure 4-10 Extended Fabric Tab
Following is a description of the fields on the Extended Fabric tab:
Port Number
Long Distance Setting
OK
Apply
Close
Reset
4-56
Port Number being used for the Extended Fabric.
Click to view Long Distance settings.
Click to save the changes made to the tab and to exit the tab.
Click to save the changes made to this tab and to stay in the current tab.
Additional changes can be made and the Apply button pressed when
making changes incrementally.
Click to exit the current tab. If changes have been made but not
committed by clicking the Apply button, a dialog box displays.
Click to reset the tab to the last set of committed changes. If the Apply
button has not been pressed on this tab, the parameters are returned to
the original values the tab had when it was initially displayed.
