OK
Apply
Close
Clr All
WWN Config
Use the WWN Config tab to specify which zones comprise a WWN Zone Configuration file. The
WWN Config tab is shown in Figure 3-17.
Figure 3-17 WWN Config tab of the WWN Level Zoning menu
Following is a description of the fields on the WWN Config tab.
Cfg Name
Create Cfg
Delete Cfg
Rename Cfg
Web Tools User's Guide
Select OK to the changes to the switch and exit the window.
Click to apply all changes made including changes made on
other tabs in the view. Changes cannot be cancelled once they
are applied.
Click to exit the window without making any changes to the
switch.
Click to clear all Aliases, Zones, Configs, FA Zones locally on
the client.
Select to modify an existing WWN configuration name to be
modified.
Click to create a new WWN configuration.
Click to delete a WWN configuration.
Click to rename a WWN configuration.
3
Fabric View
3-31
