Fabric View
Config
Use the Config tab to save and enable a Mixed Zone Configuration File. A Mixed Zone
Configuration file can contain any type of zoneable objects, ports, WWNs and AL_PAs. The
Config tab is shown in Figure 3-26.
Figure 3-26 Config tab of the Mixed Level Zoning menu
Following is a description of the fields on the Config tab.
Cfg Name
Create Cfg
Delete Cfg
Rename Cfg
Zone/QLoop Selection List
Add Mem
Remove Mem
3-48
Select the existing Cfg name to be modified.
Click to create a new configuration.
Click to delete a configuration.
Click to rename a configuration.
A list of Zone/QuickLoop members available to add to the
configuration.
Click to add a member from the Zone Selection list into the
Config Member list.
Click to remove a member from the Config Members list into
the Zone Selection list.
