HP StorageWorks 8B - FC Entry Switch User Manual page 71

Search Mem
Config Members
Analyze Config
Refresh Fabric
Enable Config
Disable Zoning
Ref Zone
A/D WWN
Rpl WWN
OK
Apply
Close
Clr All
Web Tools User's Guide
Click to search for a Switch name, WWN, Alias, Zone, Quick
Loop in the Member Selection List based on the type of objects
displayed in that list.
A list of the members that belong to the Configuration
currently selected in the Cfg Name field. The name of this list
depends on the name of the configuration selected. If a
configuration is not selected, the name displays as "null
Members".
Click to analyze the configuration that is selected along with its
member zones and aliases, and comes up with a zoning error
screen (See Zoning Configuration Analysis screen on page
3-23 in the event of a conflict).
Click to refresh the fabric view with the latest Domain/Port and
WWN changes.
If this option is checked, and the Apply button pressed, the
selected config would be used for zoning the fabric.
Select this option and press the Apply button to disable the
selected zoning configuration.
Click to reload the local zoning data base copied from the
switch. This button automatically flashes red/gray if the fabric
zoning data is changed by another client.
Click to add or delete a WWN to or from all the Aliases, Zones
defined.
Click to replace a WWN with another one in all Aliases, Zones
defined.
Applies the changes to the switch and exits the window.
Click to apply all changes made including changes made on
other tabs in the view. Changes cannot be cancelled once they
are applied.
Click to exit the window without making any changes to the
switch.
Select to clear all Aliases, Zones, and Configs, locally on the
window.
3
Fabric View
3-49
