Network Configuration Tab
Use the Network Configuration tab to manage the IP networking functionality of the switch. Both
Ethernet and FC IP networking is configured and the SYSLOG daemon message recipients. The
Network Configuration tab is shown in Figure 4-11.
Figure 4-11 Network Configuration Tab
Following is a description of the fields on the Network Configuration tab:
Ethernet IP
Ethernet SubnetMask
Gateway IP
Fibre Channel IP
Fibre Channel
SubnetMask
Syslog IP/~6
Web Tools User's Guide
Displays the Ethernet IP address.
Displays the Ethernet SubnetMask address.
Displays the Gateway IP address.
Displays the Fibre Channel IP address.
Displays the Fibre Channel SubnetMask address.
Displays six Syslog IP addresses for a user to configure.
4
Switch View
4-57
