Port Zone Tab
Use the Port Zone tab to specify which ports on a switch are to be in the selected zone and to create
and manage zones. A zone can have one or multiple members, and can include switches, ports,
WWNs, aliases, and QuickLoop AL_PAs. The Port Zone tab is shown in Figure 3-8.
Figure 3-8
Following is a description of the fields on the Port Zone tab.
Zone Name
Create Zone
Delete Zone
Rename Zone
Search Mem
Member Selection
List
Web Tools User's Guide
The Port Zone tab of the Switch/Port Level Zoning menu
To modify an existing zone, select a zone name.
Select to create a new zone. A dialog displays in which you can enter the
name of the new zone. All names must be unique and contain no spaces.
Select to delete the zone selected in the Zone Name field. Deleting a zone
automatically removes it from all zone configurations.
Select to edit the name of the zone selected in the Zone Name field. A
dialog displays in which you can edit the name of the zone.
Select to search the list of potential zone members.
A list of potential zone members, including switches, ports, WWNs,
aliases, and QuickLoop AL_PAs, and Fabric Assists.
