Config Default
Available in the Host Details section:
Protocol
User name
Host IP
Filename
Available in the Boot Options section:
FastBoot
Reboot
Power on Self-Test
Reboot After
Download
OK
Apply
Close
Reset

SNMP Tab

Use the SNMP tab for administration of the SNMP Subsystem. From the SNMP tab you can
specify the switch community string, location, trap level and trap recipients. The SNMP tab is
shown in Figure 4-5.
Note:
Web Tools User's Guide
Select the radio button to reset the configuration to the default value.
Select the pull-down menu to chose the downloading protocol.
Enter the User Name.
Enter the IP address of the host.
Enter the filename to be downloaded.
Select the radio button to do a Fastboot on the switch. This will allow
the switch to skip over the POST test.
Select the radio button to reboot the switch.
Check the box to have the switch do a POST test when it reboots or
uncheck the box to skip POST test for next reboot.
Check the box to have the switch reboot automatically after the
firmware download.
Select and exit the tab to save any changes made.
Select to save any changes made to this tab and remain in the tab.
Additional changes can be made and the Apply button pressed when
making changes incrementally.
Select to exit the Firmware/Configuration file tab. If changes have
been made and not committed, a dialog box will display asking if
want to save the changes.
Select to reset the tab to the last set of saved changes.
In order for the switches to send SNMP traps, you must first enter the Telnet command
snmpMibCapSet. This enables the MIBs on all switches to be monitored.
