HP StorageWorks 8B - FC Entry Switch User Manual page 46

3
Fabric View
WWN Aliases
Use the WWN Alias tab to configure WWN Aliases.
Figure 3-13 shows the WWN Alias tab.
Figure 3-13 WWN Alias tab of the WWN Level Zoning menu
Following is a description of the fields on the WWN Alias tab.
Alias Name
Create Alias
Delete Alias
Rename Alias
Member Selection List
3-24
Select an existing alias to modify.
Click to create a new alias. A dialog displays in which you can enter
the name of the new alias. All names must be unique and contain no
spaces.
Click to delete the alias selected in the Alias Name field. Deleting an
alias automatically removes it from all zones.
Click to rename the alias selected in the Alias Name field. A dialog
displays in which you can edit the alias name. Renaming an alias
automatically renames it in all zones.
A list of potential alias members, including switches, ports, WWNs,
and QuickLoop AL_PAs, and Fabric Assists.
Web Tools User's Guide
