Following is a description of the fields on the Quick Loop tab.
QuickLoop Name
Create Qloop
Delete Qloop
Rename Qloop
Switch Selection List
QuickLoop Members
Search Mem
Add Mem
Remove Mem
Ref Zone
A/D WWN
Rpl WWN
OK
Apply
Close
Clr All
Web Tools User's Guide
Select an existing QuickLoop member to modify.
Click to create a new Quickloop member.
Click to delete a Quickloop member.
Click to rename a Quickloop member.
This field displays a list of potential QuickLoop members, including
switches, ports, WWNs, and QuickLoop AL_PAs, and Fabric Assist.
This field displays a list of the zone members selected in the
QuickLoop Name field. The name on this list depends on the name of
the selected QuickLoop member. If a name is not selected, the name
displays as "null Members".
Click to search for a Switch name, WWN, Alias, Zone, QuickLoop, in
the Member Selection List based on the type of objects displayed in
that list.
Click to add a member from the member selection list into the
QuickLoop member contents.
Click to remove a member from the QuickLoop member list when
selected.
Click to refresh the local zoning data base copied from the switch.
This button automatically flashes red/gray if the fabric zoning data is
changed by another client.
Click to add or delete a WWN to or from all the aliases, zones
defined.
Click to replace WWN with another one in all aliases, zones defined.
Click to apply the changes to the switch and exit the window.
Click to apply the changes to the switch.
Click to exit the window without making any changes to the switch.
Select to clear all Aliases, Zones, and Configs locally on the window.
