3
Fabric View
AL_PA Device Config
Use the AL_PA Device Config tab to specify the Device Zone that belongs to the Device Zone
Configuration file. All members of this configuration file must be Zones consisting entirely of
AL_PAs in a QuickLoop. The AL_PA Device Config tab is shown in Figure 3-21.
Figure 3-21 AL_PA Device Config tab of the AL_PA Level Zoning menu
Following is a description of the fields on the AL_PA Device Config tab.
Cfg Name
Create Cfg
Delete Cfg
Rename Cfg
Zone/QLoop Selection List
Add Mem
Remove Mem
Search Mem
3-38
Select an existing AL_PA Configuration name to modify.
Click to create a new AL_PA configuration.
Click to delete a AL_PA configuration.
Click to rename a AL_PA configuration.
A list of Zone/QuickLoop members available to add to the
AL_PA configuration.
Click to add a member from the Zone Selection List into the
Configuration Member List.
Click to remove a member from the Zone Selection List into
the Configuration Member List.
Click to search for a Switch name, WWN, Alias, Zone, Qloop
in the Member Selection List based on the type of objects
displayed in that list.
