Port View

This chapter describes the views and interfaces available through the Port View in Web Tools,
which consist of the following:
Port Information View on page 5-1
Note:

Port Information View

The Port Information View displays statistics for the selected port. This information is
automatically updated when the view is opened, and is also refreshed periodically while the view
remains open.
To access Port Information View:
1. Launch the Web browser.
2. Enter the switch name or IP address in the Location/Address field and press Enter.
(Example: http://switch name/)
Web Tools launches, displaying Fabric View.
3. Click the Switch icon in Fabric View.
The Switch View displays.
4. Click a Port icon.
The Port Information View displays, as shown in Figure 5-1.
Web Tools User's Guide
Switches can be accessed through different methods, such as through the Front Panel,
Telnet, SNMP, and the Web, any of which can occur simultaneously. To verify that
modifications are correctly applied, ensure that the switch is modified from only one
connection at a time.
Chapter
5
5-1
