AL_PA Config Members
name
Analyze Config
Enable Config
Disable Zoning
Refresh Fabric
Ref Zone
A/D WWN
Rpl WWN
OK
Apply
Close
Clr All
Web Tools User's Guide
This field displays a list of the members that belong to the
AL_PA Configuration currently selected in the Cfg Name field.
The name of this list depends on the name of the AL_PA
configuration selected. If a AL_PA configuration is not
selected, the name displays as "null Members".
Click to analyze the configuration that is selected along with
it's member zones and aliases, and comes up with a zoning
error screen (See Figure 3-13) in the event of a conflict.
Select this option and press the Apply button to enable the
selected config for zoning the fabric.
Select this option and press the Apply button to disable the
selected config for zoning the fabric.
Click to refresh the fabric view with the latest Domain/Port and
WWN changes.
Click to refresh the local zoning data base copied from the
switch. This button automatically flashes red/gray if the fabric
zoning data is changed by another client.
Click to add or delete a WWN to or from all the Aliases, Zones
defined.
Click to replace a WWN with another one in all Aliases, Zones,
defined.
Applies the changes to the switch and exits the switch.
Click to apply all changes made including changes made on
other tabs in the view. Changes cannot be cancelled once they
are applied.
Click to exit the window without making any changes to the
switch.
Click to clear all Aliases, Zones, Configs locally on the switch.
3
Fabric View
3-39
