Fabric View

This chapter describes the views and interfaces available through the Fabric View of Web Tools,
which consist of the following:
•

Fabric Events View

•
Fabric Topology View
•
Name Server Table View
•
Zone Administration View
Note:
Fabric View
The Fabric View is the first Web page that displays when you connect to a switch, and it provides
access to specific information about each switch, in addition to other options and a legend
explaining the colors used to indicate switch status. Every switch in the fabric is represented by a
switch panel in Fabric View and can be managed from Web Tools.
To launch Web Tools and access Fabric View:
1. Launch Web Tools
See Launching Web Tools on page 2-4 for more information.
The Fabric View displays by default.
Note:
Web Tools User's Guide
Switches can be accessed through different methods, such as through the Front Panel,
Telnet, SNMP, and the Web, any of which can occur simultaneously. To verify that
modifications are correctly applied, ensure that the switch is modified from only one
connection at a time.
This switch is assumed to be the local domain.
For information specific to a QuickLoop to be available, the QuickLoop switch must
be the host domain.
