Introducing Web Tools

Capabilities of Web Tools

Web Tools provides the following information and capabilities:
•
Monitoring and managing the entire fabric.
•
Monitoring and managing individual switches.
•
Monitoring and managing individual ports.
When monitoring and managing the entire fabric, Web Tools allows you to perform the following
functions:
View the status of all the switches in the fabric. See Fabric View on page 3-1.
Access event logs for entire fabric.
Set-up and manage Zoning functions.
Access to the Name Server Table.
Access Telnet functions.
Use switch beaconing for rapid identification in
large fabric environments.
Name and zone QuickLoops.
When monitoring and managing individual switches, Web Tools allows you to perform the
following functions:
View summary information about each switch.
View event logs for individual switches.
Perform switch configuration and
administration.
Use the ability to upgrade Fabric OS and
license key administration.
Use report capability for switch configuration
information.
1-2
See Fabric Events View on page 3-5
See The Name Server Table also includes
the following columns: on page 3-10.
See Name Server Table View on page 3-8.
See Telnet Interface on page 4-64.
See Beacon on page 4-4.
See Loop Tab on page 5-8 or the
QuickLoop Tab on page 4-50.
See Config on page 3-48.
See Switch Events View on page 4-4.
See Administrative Interface on page 4-38,
the Switch Settings Tab on page 4-40, and
the Current Settings tab in the Fabric
Watch View on page 4-17.
See Firmware/Configuration File
Administration Tab on page 4-43.
See Report Tab on page 4-63.
