HP StorageWorks 8B - FC Entry Switch User Manual page 58

3
Fabric View
Add Mem
Remove Mem
Ref Zone
A/D WWN
Rpl WWN
OK
Apply
Close
Clr All
Quick Loop
Use the Quick Loop tab to create and manage Quick Loops. For information on managing the
Quick Loop feature separately, see Loop Tab in this document. The Quick Loop tab is shown in
Figure 3-20.
Figure 3-20 Quick Loop tab of the AL_PA Level Zoning menu
3-36
Click to add a member from the member selection list into the Zone
Members list.
Click to remove a member from the Zone Member List when selected.
Click to refresh the local zoning data base copied from the switch.
This button automatically flashes red/gray if the fabric zoning data is
changed by another client.
Click to add or delete a WWN to or from all the aliases, zones defined
Click to replace WWN with another one in all aliases, zones defined.
Click to apply the changes to the switch and exit the switch.
Click to apply the changes to the switch.
Click to exit the window without making any changes to the switch.
Click to clear all aliases, zones, configs locally on the switch.
Web Tools User's Guide
