2 If your mirrored or RAID 5 array has a Not in Use member
drive, the drive may still be usable. Try rebuilding with the Not
in Use drive intact. Simply select the array and then the Rebuild
button.
3 Confirm that you selected the correct array by hitting OK in the
Rebuild confirmation display.
4 Select F8 to exit the Disk Array Configuration Utility. The
array will begin rebuilding after completion of the operating sys-
tem load.
5 If the rebuild fails and you have no Available Drives, you must
power down the system and replace the failed or Not In Use
drive. Power on the system and enter the Disk Array Configu-
ration Utility.
6 Select an available drive to replace the faulted drive in the array
by navigating the cursor over the available drive and hitting
Enter (see Figure 20). An asterisk in the left most column indi-
cates the drive is selected.
7 Navigate to the degraded array and press Enter to select it.
