3ware Escalade ATA RAID Controller User Guide

Windows Installation

Installing 3DM for Windows NT, Windows 98/
ME, Windows 2000, Windows XP
1 Insert the 3DM installation media into the CD-ROM.
2 Run the 3DMsetup.exe program found on the installation disk.
You may do this using Windows Explorer by double-clicking on
the Setup file found on the installation disk or by executing run
d:\windows\3dm\3dmsetup.exe from the Run... in the Start
menu.
3 The 3DM Setup Standard install window will guide you
through the installation process.
4 At the Remote Monitoring and Security Configuration win-
dow (see Figure 47), check the first checkbox to change the
HTTP port that you would like 3DM to use. If you do not know
what port to use, leave the box unchecked and use the default
port. If choose to change the HTTP port and enter port 0, the
web interface will be disabled (not recommended). If the second
checkbox is checked, only localhost connections are allowed
(Internet and Intranet connections are not allowed). Uncheck the
second checkbox if Internet and Intranet connections are
desired.
144 www.3ware.com
