3ware Escalade ATA RAID Controller User Guide
• The number of 3ware ATA RAID controllers in the system is
also displayed, as well as the current version of the operating
system including service level and any service packs that are
installed.
• Detailed information for each controller is displayed, such as its
model number, serial number, firmware and BIOS versions, unit
count (total number of disk arrays on the controller), and version
numbers of the chips on the 3ware card.
• Information is displayed on each unit (a unit is a disk array or
JBOD). The array status, capacity, write cache status, RAID
type, and subunits in the array are displayed.
• Information is displayed on each subunit (a subunit is a drive
used in a particular array). The individual drive status for each
drive is displayed.
• Under drive count is displayed. Detailed information on the indi-
vidual disk drives, such as disk drive status, disk drive capacity,
model number, and serial number.
