Figure 13. Create Disk Array Display, Raid 5 Example - 3Ware 7000-2 - Escalade RAID Controller User Manual

Note: Creating an array will overwrite existing data on its drives.
Create a disk array from these drives:
Port 1
Port 2
Port 3
Select RAID Configuration:
Array's Write Cache State:
Alt-F1 Help

Figure 13. Create Disk Array Display, RAID 5 Example

Select RAID configuration
The Escalade ATA RAID Controller gives you a choice of four
RAID configurations. Select one.
• Stripe (RAID 0): maximizes performance and capacity through a
process called striping. High performance arrays write portions
of a single file across multiple drives. There is no fault tolerance.
• Mirror (RAID 1): duplicates or "mirrors" the data on both
drives. No data will be lost if one of the drives fails.
• RAID 10: combines mirroring and striping, providing both fault
tolerance and high performance. RAID 10 arrays require a
minimum of four drives. Configurations consist of 4, 6, 8, 10
or 12 drives.
• RAID 5: combines parity data and striping, providing fault toler-
ance, high capacity and high storage efficiency. The parity data
is distributed across all drives, rather than being concentrated on
