2 Install two jumpers on the converter if not already installed. See
Figure 7 for location to set jumper settings.
3 Connect a Power Converter Adapter to each converter. See
Figure 7 for connector locations.
4 When you have completed steps 2 and 3 for each converter,
install a Converter onto the back of each parallel ATA drive.
Make sure that each converter is properly aligned and securely
pushed in. The converter board's power connector must be adja-
cent to the drive's power connector. See Figure 7.
Note:
Please use caution when pushing the converter onto the
back of the drive.
5 Connect the Power Adapter to the power receptacle on the drive.
6 If your drives are not already installed in the computer chassis,
install them now. Be sure that the drives are connected to the
power supply.
7 Connect each power adapter to the power supply.
8 For each drive, select the end of an interface cable not connected
to the ATA RAID Controller and plug it into the Converter.
www.3ware.com
The Serial ATA Converter has sharp points.
Hardware Installation
41
