3ware Escalade ATA RAID Controller User Guide
• Handle the ATA RAID Controller by its edges or by the black
rail and metal bracket at its two ends.
• Don't touch any pin, contact, lead or component on the ATA
RAID Controller.

Mechanical Concerns

Be careful when installing the Escalade ATA RAID Controller into
your system. Excessive force can damage the board, the cables,
your drives or your system.
• Be sure the board is aligned with its slot on the motherboard
before installing. Do not flex the board excessively.
• Interface cable connectors must be mated carefully without
bending any pins. The connectors provided are keyed to prevent
you from inserting them upside-down.
• Interface cables are fragile and must not be crimped or pinched.
Ensure that they do not impede the flow of cooling air from fans
or heat sinks in the system case.
18 www.3ware.com
