2 One edge of each interface cable connector is keyed to ensure
proper orientation and installation. Carefully mate the connec-
tors without bending any pins.
3 Install the other connectors in the same manner.
Note:
susceptible to damage from excessive bending.
1 If the computer is running, shut it down. Turn off power to the
computer and disconnect the power cord from the outlet.
2 Open the computer case according to the manufacturer's instru-
tions.
3 Find the PCI slot you want to use for the serial ATA RAID Con-
troller.
Hint:
ATA RAID Controller next to an open slot.
4 Remove the metal filler bracket for the slot. Save this screw; it
will be used to secure the serial ATA RAID Controller after you
have seated it in the slot.
Hint:
in any PCI slot, not all slots give equal performance due
to the architecture of the PCI bus. In our laboratories, we
have noticed that the slots closest to the Accelerated
Graphics Port (AGP) or in the 64-bit PCI slot typically
give the best performance. Our card should fit in both
32-bit and 64-bit PCI slots with 5V as well as with 3.3V.
5 Line up the ATA RAID Controller so that all pins make proper
contact with the PCI slot pins when pushed into place. The
www.3ware.com
The connectors on the end of the controller are
Cable routing may be easier if you install the
While the ATA RAID Controller runs properly
Hardware Installation
39
