3ware Escalade ATA RAID Controller User Guide

Installing a Parallel ATA RAID Controller

Note:
Controller, continue to page 38 "Installing a Serial ATA
RAID Controller".
JP2 LED drive status connector
Note: Pin 1 and 4 are 3.3V
and pin 2 and 3 are ground
Plug cable to either pins 1 and 2
or pins 3 and 4.
Ports:
7
Serial Number
(on plate)
Figure 5. 8-Port Escalade 7500-8 ATA RAID
Controller Layout
Connect the interface cables to the Escalade ATA RAID
Controller
1 Connect the interface cables supplied with the product to the
ATA RAID Controller. See Figure 5.
34
If you are not installing a Parallel ATA RAID
4
5
6
0
1
2
3
0
www.3ware.com
