Note:
133 drives require 40-pin, 80-conductor ribbon
cables. These cables have color coded ends. For opti-
mum performance, the blue end must be connected to the
ATA RAID Controller and the black end must be con-
nected to the hard drive.
2 One edge of each interface cable should have a colored (usually
red) line denoting the conductor to Pin 1. Align the ATA RAID
Controller so that the colored line is toward the top edge of the
controller. Mate the connectors carefully without bending any
pins.
3 Install the other connectors in the same manner.

Install the Escalade ATA RAID Controller in the computer

1 If the computer is running, shut it down. Turn off power to the
computer and disconnect the power cord from the outlet.
2 Open the computer case according to the manufacturer's instruc-
tions.
3 Find the PCI slot you want to use for the ATA RAID Controller.
Hint:
ATA RAID Controller next to an open slot.
4 Remove the metal filler bracket for the slot. Save this screw; it
will be used to secure the ATA RAID Controller after you have
seated it in the slot.
www.3ware.com
UltraATA-66, UltraATA-100 and UltraATA-
Cable routing may be easier if you install the
Hardware Installation
35
