Available Drives:
Disk Arrays:
Array Unit 0 - 4 drive 64K RAID 10
Port 0 - QUANTUM FIREBALLP LM30
Port 1 - QUANTUM FIREBALLP LM30
Port 2 - QUANTUM FIREBALLP LM30
Port 3 - QUANTUM FIREBALLP LM30
Create Array
Alt-F1 Help
Restore Initial Values
F6

Figure 18. Degraded RAID 10 Array Drive When Not in Use

Note:
four, six, eight, ten or twelve drives. In a 4-drive config-
uration, up to two drives can be rebuilt. In a 6-drive con-
figuration, up to three drives can be rebuilt. In an 8-drive
configuration, up to four drives can be rebuilt. In a 12-
drive configuration, up to six drives can be rebuilt.

Rebuilding a RAID 5 disk array

Escalade ATA RAID Controllers allow you to create fault tolerant
RAID 5 disk arrays. These disk arrays achieve fault tolerance by
using a simple (exclusive OR) function to generate the parity data
www.3ware.com
3 w a r e D i s k A r r a y C o n f i g u r a t i o n
Delete Array
$ Toggle Hot Spare
Previous/Next
Esc
A RAID 10 array can be configured with either
3ware Disk Array Configuration Utility
60.0GB DEGRADED
30.0GB
30.0GB
30.0GB
30.0GB
Maintain Array
Enter
Cancel F8
Done
Not in Use
Rebuild Array
Select/Deselect
59
