3ware Escalade ATA RAID Controller User Guide
Escalade ATA RAID Controller is keyed to ensure proper instal-
lation into a full-sized PCI slot.
6 Ensure that the contacts will mate with both grooves in the slot.
Press down gently on the edge of the ATA RAID Controller
directly above the slot until it is fully seated.
7 Check that the ATA RAID Controller's metal bracket covers the
hole in the case and secure the bracket with the screw that was
used to secure the filler bracket in step 4.

Connect the drives to the interface cables

Using native serial ATA drives
1 If your drives are not already installed in the computer chassis,
install them now. Be sure that the drives are connected to the
power supply.
2 For each drive, select the end of an interface cable not connected
to the ATA RAID Controller and plug it into the drive or drive
carrier. One edge of each interface cable connector is keyed to
ensure proper installation.
Using parallel ATA-133 or ATA-100 drives with converter kit
(CBL-P-SATA)
Note:
supported.
1 Before connecting your drives, check each drive's jumper set-
ting. The range of settings vary by manufacturer as do the
method for adjusting them. Refer to information provided with
your drives for the method required to set them. To operate prop-
erly, the Escalade ATA RAID Controller requires that drives be
set as Single (if available on your drive) or Master.
40
UltraATA-66 and UltraATA-33 drives are not
