3Ware BBU Remote Battery Installation Manual

Remote battery board

Advertisement

Remote Battery Installation
Guide
The remote battery board is intended for use with a 3ware
9550SX(U), 9650SE, or 9690SA RAID controller to mount the
battery off the controller. The remote battery board is optional with
the 3ware 9550SX(U) and 9650SE, but is required with the
9690SA.

Contents of this package

Battery Backup Unit (BBU) control module
Battery
Battery extension cable
Remote battery board with full height bracket
Low-profile bracket for low-profile enclosures.
Remote Battery Installation Guide (this document)

Before You Start

Installation details covered in your 3ware RAID controller
Installation Guide are not duplicated in this guide. Please follow
those instructions on how to:
Install your 3ware RAID controller
Mount the BBU control module on the controller (
mount the battery on the RAID controller)
Primary installation instructions for your Battery Backup Unit
(BBU) are provided in the Installation Guide that came with your
3ware RAID controller. If you do not have a hardcopy, you can
download a PDF of your Installation Guide from
http://3ware.com/support/userdocs.asp.
www.3ware.com
PN: 720-0171-00
Do not
Note:
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BBU Remote Battery and is the answer not in the manual?

Questions and answers

Summary of Contents for 3Ware BBU Remote Battery

  • Page 1: Before You Start

    Primary installation instructions for your Battery Backup Unit (BBU) are provided in the Installation Guide that came with your 3ware RAID controller. If you do not have a hardcopy, you can download a PDF of your Installation Guide from http://3ware.com/support/userdocs.asp.
  • Page 2: Installation Instructions

    Remove the metal filler brackets for the expansion slots. Save the screws; they will be used to secure the 3ware RAID controller and remote battery board after you have installed them in the slots.
  • Page 3 1. Press down gently on the battery module until the bottom clip snaps into place in the lower hole. Figure 2. Attaching the battery module to the remote board Bottom clip will snap in here www.3ware.com...
  • Page 4 Copyright ©2007 Applied Micro Circuits Corporation (AMCC). All rights reserved. 3ware®, 3DM® are registered trademarks of AMCC. The 3ware logo, 3BM, StorSave are all trademarks of AMCC. All other trademarks herein are property of their respective owners.
