Intel® Server Chassis SR2400
User Guide
Order Number: C51501-002

Advertisement

Table of Contents
loading

Related Manuals for Intel SR2400

Summary of Contents for Intel SR2400

  • Page 1 Intel® Server Chassis SR2400 User Guide Order Number: C51501-002...
  • Page 2 Intel’s own chassis are designed and tested to meet the intended thermal requirements of these components when the fully integrated system is used together. It is the responsibility of the system integrator that chooses not to use Intel developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow required for their specific application and environmental conditions.

  • Page 3: About This Manual

    Manual Organization Chapter 1 provides a brief overview of the Server Chassis SR2400. In this chapter, you will find a list of the server chassis features, pictures of the product, and product diagrams to help you identify components and their locations.
  • Page 4 ® Local Control Panel The contents list includes only items included with the Intel Server Chassis SR2400. This list does not include items that are shipped and pre-installed in the Intel Server Platform SR2400JR2. Before purchasing any required options, refer to your server board documentation to determine which option(s) are supported on your server board.
  • Page 5 Kit to convert a hard drive bay to a floppy drive bay For information about which of these items have been tested and can be used with your chassis, and for ordering information for Intel products, see http://www.support.intel.com/support/motherboards/server/chassis/SR2400/ Before purchasing any optional items, refer to your server board documentation to determine which items...

  • Page 6: Additional Information And Software

    BIOS settings and chipset information If you just received this product and Intel® Server Chassis SR2400 Quick Start User’s Guide in the product box need to install it For virtual system tours and A link to the SMaRT Tool is available under “Other Resources” at the right side...

  • Page 7: Safety Information

    To ensure EMC compliance with your local regional rules and regulations, the final configuration of your end system product may require additional EMC compliance testing. For more information please contact your local Intel Representative. See “Regulatory and Integration Information” for product Safety and EMC regulatory compliance information.

  • Page 8: Warnings

    Warnings System power on/off: The power button DOES NOT turn off the system AC power. To remove power from system, you must unplug the AC power cord from the wall outlet. Make sure the AC power cord is unplugged before you open the chassis, add, or remove any components.

  • Page 9: Safety Cautions

    Safety Cautions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information at http://support.intel.com/support/motherboards/server/sb/CS-010770.htm. The power supply in this product contains no user-serviceable parts. There may be more than one supply in this product.
  • Page 10 For proper cooling and airflow, always reinstall the chassis covers before turning on the system. Operating the system without the covers in place can damage system parts. To install the covers: Check first to make sure you have not left loose tools or parts inside the system.

  • Page 11: Wichtige Sicherheitshinweise

    Preface Wichtige Sicherheitshinweise Lesen Sie zunächst sämtliche Warn- und Sicherheitshinweise in diesem Dokument, bevor Sie eine der Anweisungen ausführen. Beachten Sie hierzu auch die Sicherheitshinweise zu Intel- Serverplatinen und Servergehäusen unter http://support.intel.com/support/motherboards/server/sb/CS-010770.htm. Benutzer können am Netzgerät dieses Produkts keine Reparaturen vornehmen. Das Produkt enthält möglicherweise mehrere Netzgeräte.
  • Page 12 Zur ordnungsgemäßen Kühlung und Lüftung muß die Gehäuseabdeckung immer wieder vor dem Einschalten installiert werden. Ein Betrieb des Systems ohne angebrachte Abdeckung kann Ihrem System oder Teile darin beschädigen. Um die Abdeckung wieder anzubringen: Vergewissern Sie sich, daß Sie keine Werkzeuge oder Teile im Innern des Systems zurückgelassen haben.
  • Page 13 Consignes de sécurité Lisez attention toutes les consignes de sécurité et les mises en garde indiquées dans ce document avant de suivre toute instruction. Consultez Intel Server Boards and Server Chassis Safety Information sur le site http://support.intel.com/support/motherboards/server/sb/CS-010770.htm. Le bloc d'alimentation de ce produit ne contient aucune pièce pouvant être réparée par l'utilisateur.
  • Page 14 Une fois TOUTES les étapes précédentes accomplies, vous pouvez retirer les panneaux du système. Procédez comme suit: Si un cadenas a été installé sur à l’arrière du système, déverrouillez-le et retirez-le. Retirez toutes les vis des panneaux et mettez-les dans un endroit sûr. Retirez les panneaux.

  • Page 15: Instrucciones De Seguridad Importantes

    Instrucciones de seguridad importantes Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en en http://support.intel.com/support/motherboards/server/sb/CS-010770.htm. El usuario debe abstenerse de manipular los componentes de la fuente de alimentación de este producto, cuya reparación debe dejarse exclusivamente en...
  • Page 16 Para obtener un enfriamiento y un flujo de aire adecuados, reinstale siempre las tapas del chasis antes de poner en marcha el sistema. Si pone en funcionamiento el sistema sin las tapas bien colocadas puede dañar los componentes del sistema. Para instalar las tapas: Asegúrese primero de no haber dejado herramientas o componentes sueltos dentro del sistema.
  • Page 17 Preface AVVERTENZA: Italiano Rivolgersi ad un tecnico specializzato per la riparazione dei componenti dell'alimentazione di questo prodotto. È possibile che il prodotto disponga di più fonti di alimentazione. Non modificare o utilizzare il cavo di alimentazione in c.a. fornito dal produttore, se non corrisponde esattamente al tipo richiesto.
  • Page 18 Se il sistema è stato a lungo in funzione, il microprocessore e il dissipatore di calore potrebbero essere surriscaldati. Fare attenzione alla presenza di piedini appuntiti e parti taglienti sulle schede e sul telaio. È consigliabile l'uso di guanti di protezione. Esiste il pericolo di un esplosione se la pila non viene sostituita in modo corretto.

  • Page 19: Table Of Contents

    Removing the Fixed Drive Air Baffle (No Backplane Installed) ........51 Installing the Fixed Drive Air Baffle (No Backplane Installed) ........52 Removing and Installing the Fan Module................53 Removing the Fan Module ................... 53 Installing the Fan Module ..................... 54 Intel® Server Chassis SR2400 User Guide...
  • Page 20 Installing and Removing a Hard Disk Drive................56 Removing a SATA or SCSI Hot-swap Hard Disk Drive..........56 Installing a SATA or SCSI Hot-swap Hard Disk Drive..........57 Installing a Fixed SATA Hard Disk Drive..............61 Removing a Fixed SATA Hard Disk Drive..............66 Installing the SATA or SCSI Sixth Drive Accessory ..............
  • Page 21 ® Intel Server Issue Report Form..............126 Warranty......................130 Limited Warranty for Intel ® Chassis Subassembly Products..........130 Extent of Limited Warranty....................130 Warranty Limitations and Exclusions .................. 131 Limitations of Liability ....................131 How to Obtain Warranty Service..................132 Telephone Support.....................
  • Page 22 Figure 24. Installing the Fan Module..................55 Figure 25. Removing the Hot-swap Hard Drive Carrier from the Chassis ......... 56 Figure 26. Removing the Retention Device from the Hot-swap Drive Carrier......57 Figure 27. Attaching a Hot-swap Hard Disk Drive to a Drive Carrier ......... 57 Figure 28.
  • Page 23 Contents Figure 73. Removing the Tape Drive Bay Filler Panel ............. 107 Figure 74. Inserting a Tape Drive into the Carrier..............108 Figure 75. Inserting the Tape Drive Carrier into the Chassis ........... 108 Figure 76. Connecting the Tape Drive Cables................. 109 Figure 77.
  • Page 24 xxiv...

  • Page 25: Server Chassis Features

    The Intel® Server Chassis SR2400 is shown in the following picture. ® Figure 1. Intel Server Chassis SR2400 Intel®...

  • Page 26: Table 1. Server Chassis Features

    Two non-redundant fans in power supply Standard Control Panel Control Panel (dependent on option selected) Intel® Local Control Panel (requires installation of the optional Intel® Management Module – Advanced or Intel® Management Module – Professional) With Standard Control Panel: LEDs and displays...
  • Page 27 Lock attach point for chassis cover One front panel USB port with Standard Control Panel ® Two front panel USB ports with Intel Local Control Panel Two back panel USB ports One front panel video port (available only with the Standard Control Panel)

  • Page 28: Component Identification

    Component Identification Internal Components TP01087 A. Power supply module housing F. Fan module (shown with optional redundant fans) B. Power distribution module G. SATA or SCSI backplane (optional component) C. PCI Riser assembly H. Drive bay area (drives not included) D.

  • Page 29: Hot-Swap Sata Backplane Connections

    Server Chassis Features Hot-Swap SATA Backplane Connections The diagram below shows the connection points on the rear of the SATA backplane. The power supply, server board and a SATA RAID card can be connected to the locations below. TP01363 A. OPT connector F.

  • Page 30: Standard Control Panel

    The diagram below shows the features available on the Standard Control Panel. The Standard Control Panel is one of two required control options that can be selected. The other option is the ® Intel Local Control Panel. For instructions on installing the Standard Control Panel, see “Replacing the Control Panel.”...

  • Page 31: Intel Local Control Panel

    Intel Local Control Panel ® The diagram below shows the features available on the Intel Local Control Panel. The Intel Local Control Panel is one of two required control options that can be selected. The other option is the Standard Control Panel. For instructions on installing the Standard Control Panel, see “Replacing...

  • Page 32: Back Panel Features

    LED or SATA). No light indicates no hard disk drive activity. Reset button Reboots and initializes the system. ® Figure 6. Intel Local Control Panel Back Panel Features TP01090 A. Low-profile add-in card bracket D Power supply fans (shown...

  • Page 33: Peripheral Devices

    Figure 8. Optional Peripherals Hard Disk Drives The Intel® SR2400 chassis supports both a hot-swap (SCSI and SATA) and a non-hot-swap (SATA only) configuration. If the non-hot-swap configuration is used, before replacing a hard drive, you must first take the server out of service, turn off all peripheral devices connected to the system, turn off the system by pressing the power button, and unplug the AC power cord from the system or wall outlet.

  • Page 34: Floppy / Cd-Rom / Dvd-Rom Drives

    ROM or DVD-ROM hard drives. See “Additional Information and Software” for an Internet link to a list of supported hardware. Intel provides accessory kits for these drives. To use one of the drives provided by Intel, use the following order codes: Slimline CD-ROM Drive: AXXSCD...

  • Page 35: Advanced Management Options

    Rack-Mounted Systems Your Server Chassis SR2400 is designed to be mounted into a rack. The Intel SR2400 server chassis can be mounted using one of two accessories; the first is a tool-less rail kit and the second is a fixed rail kit.

  • Page 37: Hardware Installations And Upgrades

    Hardware Installations and Uprades 2 Hardware Installations and Upgrades Before You Begin Before working with your server product, pay close attention to the safety instructions at the beginning of this manual. See “Safety Information.” This document provides instructions for adding and replacing chassis components. For instructions on replacing components on the server board, such as the processor and memory DIMMs, see the instructions provided with the server board.

  • Page 38: Removing And Installing The Chassis Cover

    Removing and Installing the Chassis Cover Removing the Chassis Cover The Server Chassis SR2400 must be operated with the top cover in place to ensure proper cooling. You will need to remove the top cover to add or replace components inside of the chassis. Before removing the top cover, power down the server and unplug all peripheral devices and the AC power cable.

  • Page 39: Installing The Chassis Cover

    Hardware Installations and Uprades Installing the Chassis Cover 1. Place the cover over the chassis so that the side edges of the cover sit just inside the chassis sidewalls. 2. Slide the cover forward until it clicks into place. See letter “A” in the figure below. 3.

  • Page 40: Removing And Installing The Front Bezel

    Removing and Installing the Front Bezel The front bezels are available as optional accessories for the Server Chassis SR2400. Two front bezel options are available. One is used for the Standard Control Panel and the other is used with ®...

  • Page 41: Installing The Front Bezel

    Use the steps below if your system includes either the standard front bezel or the front bezel for the Intel Local Control Panel. The front bezel is optional. 1. At each end of the bezel, line up the center notch on the bezel with the center guide on the rack handles.

  • Page 42: Removing And Installing The Processor Air Duct And Processor Air Dam

    Removing and Installing the Processor Air Duct and Processor Air Dam Always operate your server chassis with the processor air duct in place. The air duct is required to maintain proper cooling of the processors. For instructions on adding or replacing a processor, first remove the processor air duct and the processor air dam, and then see your server board user guide for instructions on processor installations and removals.

  • Page 43: Installing The Processor Air Duct

    Hardware Installations and Uprades Installing the Processor Air Duct 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 44: Figure 14. Installing The Processor Air Duct

    Removing the Processor Air Dam.” 5. If you are removing a second processor, install the air dam on the underside of the air duct. For instructions, see “Installing the Processor Air Dam.” 6. Place the processor air duct over the processor socket(s). See the figure below. The front edge of the air duct should contact the fan module and the top of the installed air duct should be flush with the top surface of the power supply.

  • Page 45: Removing The Processor Air Dam

    Hardware Installations and Uprades Removing the Processor Air Dam If you install only a single processor, the processor air dam must be installed on the underside of the processor air duct. If you install two processors, the air dam must be removed from the air duct. For instructions on adding or replacing a processor, first remove the processor air duct and the processor air dam, and then see your server board user guide for instructions on processor installations and removals.

  • Page 46: Installing The Processor Air Dam

    Installing the Processor Air Dam The air dam is installed on a server board that supports two processors but only one processor is to be installed. Remove the air dam only if you will be installing a second processor. If you have removed the second processor from the server, install the processor air dam as follows: 1.

  • Page 47: Removing The Large Hot-Swap Air Baffle (Backplane Installed)

    Hardware Installations and Uprades Removing the Large Hot-swap Air Baffle (Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 48: Installing The Large Hot-Swap Air Baffle (Backplane Installed)

    Installing the Large Hot-swap Air Baffle (Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3. Remove the chassis cover. For instructions, see “Removing the Chassis Cover.”...

  • Page 49: Removing The Small Hot-Swap Air Baffle (Backplane Installed)

    Hardware Installations and Uprades Removing the Small Hot-swap Air Baffle (Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 50: Installing The Small Hot-Swap Air Baffle (Backplane Installed)

    Installing the Small Hot-swap Air Baffle (Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3. Remove the chassis cover. For instructions, see “Removing the Chassis Cover.”...

  • Page 51: Removing The Fixed Drive Air Baffle (No Backplane Installed)

    Hardware Installations and Uprades Removing the Fixed Drive Air Baffle (No Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 52: Installing The Fixed Drive Air Baffle (No Backplane Installed)

    Installing the Fixed Drive Air Baffle (No Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 53: Removing And Installing The Fan Module

    Hardware Installations and Uprades Removing and Installing the Fan Module Some installation processes will require that you remove and later re-install the fan module. The steps below describe how to remove and then install this component. Use these steps only when it is indicated as necessary for a component installation process.

  • Page 54: Installing The Fan Module

    Installing the Fan Module 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3. Remove the chassis cover. For instructions, see “Removing the Chassis Cover.”...

  • Page 55: Figure 24. Installing The Fan Module

    Hardware Installations and Uprades 5. Place the fan module over the chassis standoffs and slide the module to the right until the blue tab clicks into place. See letter “A” in the figure below. 6. Connect the folded fan module ribbon cable to the fan module. See letter “B” in the figure. 7.

  • Page 56: Installing And Removing A Hard Disk Drive

    Six hot-swap SCSI drives if both the SCSI backplane and the sixth drive kit are installed. NOTE The Intel Server Chassis SR2400 does not support all hard drives. See “Additional Information and Software” for an Internet link to a list of supported hardware.

  • Page 57: Installing A Sata Or Scsi Hot-Swap Hard Disk Drive

    Hardware Installations and Uprades 4. Remove the four screws that attach the plastic retention device or the previously installed hard drive to the drive carrier. Two screws are at each side of the retention device or the hard drive. If required, store the plastic retention device for future use. TP00787 Figure 26.

  • Page 58: Figure 28. Inserting A Hot-Swap Hard Disk Drive Assembly Into The Chassis

    5. With the black lever in the fully open position, slide the drive assembly into the chassis. The green latch at the front of the drive carrier must be to the right. See letter “A” in the figure below. Do not push on the black drive carrier lever until the lever begins to close by itself. 6.

  • Page 59: Figure 29. Connecting The Hot-Swap Sata Data Cables

    Hardware Installations and Uprades 7. (SATA installation only): Connect the SATA cable(s) labeled SATA CH A and SATA CH B to the backplane. See letter “A” in the figure below to locate the backplane. See letter “B” in the figure to identify the end of the SATA cable that is attached to the backplane. In the figure below, the SATA board showing the SATA cable connections is shown as if you were looking at the chassis from the rear.

  • Page 60: Figure 30. Connecting The Scsi Data Cable

    9. (SCSI installation only): Connect the end of the SCSI cable that is labeled “Backplane” to the backplane SCSI Connector. See letter “A” in the figure below. 10. (SCSI installation only): Connect the end of the SCSI cable that is labeled “Server Board” to the SCSI connection on the server board if not already connected.

  • Page 61: Installing A Fixed Sata Hard Disk Drive

    Hardware Installations and Uprades Installing a Fixed SATA Hard Disk Drive Use these instructions only if you have installed the fixed drive kit. CAUTION Fixed drives are NOT hot swappable. Before removing or replacing the drive, you must first take the server out of service, turn off all peripheral devices connected to the system, turn off the system by pressing the power button, and unplug the AC power cord from the system or wall outlet.

  • Page 62: Figure 32. Removing The Retention Device From The Fixed Drive Carrier

    6. Remove the four screws that attach the plastic retention device or the previously installed hard drive to the drive carrier. Two screws are at each side of the retention device or the hard drive. If required, store the plastic retention device for future use. TP01304 Figure 32.

  • Page 63: Figure 34. Installing The Fixed Sata Drive Power Cables

    Hardware Installations and Uprades 9. Insert the drive into the bay until it clicks into place. Install drives first into the lower three drive bays for the easiest cable routing. 10. If it is not already installed, connect the SATA power cable adapter to the 3x2 power supply cable that extends from your power supply.

  • Page 64: Figure 35. Installing The Fixed Sata Drive Data Cables

    11. For each drive you install, route one SATA data cable from the server board or add-in card to the hard drive, with the right-angle end of the SATA data cable connected to the server board or add-in card SATA connector. See letter “B” in the figure below and see your server board documentation or add-in card documentation for assistance in locating the SATA connectors on the board or add-in card.

  • Page 65: Figure 36. Installing The Fixed Sata Drive Power Cables

    Hardware Installations and Uprades 15. Power cables for drives installed to the right side of the air baffle must be routed beneath the front cutout in the underside of the air baffle. See letter “B” in the figure below. The power cables for drives installed to the left of the air baffle do not need to be routed under the air baffle.

  • Page 66: Removing A Fixed Sata Hard Disk Drive

    Removing a Fixed SATA Hard Disk Drive CAUTION Fixed drives are NOT hot swappable. Before removing or replacing the drive, you must first take the server out of service, turn off all peripheral devices connected to the system, turn off the system by pressing the power button, and unplug the AC power cord from the system or wall outlet.

  • Page 67: Installing The Sata Or Scsi Sixth Drive Accessory

    Hardware Installations and Uprades Installing the SATA or SCSI Sixth Drive Accessory The SATA and SCSI sixth drive accessories is used when a sixth SATA hot-swap drive or a sixth SCSI hot-swap drive is needed. The SATA or SCSI backplane accessory kit is required to install this accessory.

  • Page 68: Figure 38. Installing The Sixth Drive Board

    6. Remove the fan module. For instructions, see “Removing the Fan Module.” 7. Hold the SATA or SCSI sixth drive accessory board about ¼-inch above the opening in the backplane to allow alignment notches to clear the top of the backplane bracket. Move the board forward into the opening and set it into place while lining up the two tabs on the sixth drive kit board with the matching holes on backplane.

  • Page 69: Installing Or Removing A Floppy Drive (Slimline Or Standard)

    The carrier for the slimline floppy drive that is used in these instructions was sent to you in the hardware kit that came with your Server Chassis SR2400. 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety...

  • Page 70: Figure 39. Installing A Floppy Drive Into The Slimline Carrier

    3. Remove the chassis cover. For instructions, see “Removing the Chassis Cover.” 4. Remove the front bezel if it is installed. For instructions, see “Removing the Front Bezel.” 5. Align the two holes at the left side of the floppy drive with the two cutouts in the floppy drive carrier.

  • Page 71: Figure 41. Installing The Slimline Floppy Drive Into The Chassis

    Hardware Installations and Uprades 10. Slide the floppy drive assembly into the slimline bay of the chassis until it clicks into place. See letter “A” in the figure below. 11. Open the connector labeled “Floppy Con” on the backplane by pulling up on the connector cover.

  • Page 72: Removing A Floppy Drive From The Slimline Bay (Backplane Installed)

    Removing a Floppy Drive from the Slimline Bay (Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 73: Installing Floppy Drive Into Slimline Bay (No Backplane Installed)

    The carrier for the slimline floppy drive that is used in these instructions was sent to you in the hardware kit that came with your Server Chassis SR2400. The interposer board and floppy drive power adapter cable used in these instructions was sent to you with your fixed drive kit.

  • Page 74: Figure 43. Connecting The Flat Flex Cable To A Floppy Drive

    7. Open the connector on the rear of the floppy drive by pulling up on the connector cover. See letter “A” in the figure below. 8. Insert one end of the 26-pin flat flex cable end into the connector. See letter “B” in the figure. 9.

  • Page 75: Figure 44. Installing The Floppy Drive Interposer Board

    Hardware Installations and Uprades 13. Lower the interposer board into the floppy drive tray at the rear of the floppy drive and engage the notch on the board. See letter “A” in the figure below. 14. Attach the interposer board to floppy drive with the screw that was included with the interposer board.

  • Page 76: Figure 45. Connecting The Floppy Drive Cables

    15. Slide the floppy drive assembly into the chassis until it clicks into place. See letter “A” in the figure below. 16. Connect the 2x2 end of the floppy drive power cable that was included with your kit to the 2x2 power connector on the SATA power adapter cable.

  • Page 77: Removing A Floppy Drive From The Slimline Bay (No Backplane Installed)

    Hardware Installations and Uprades 17. Install the chassis cover. For instructions, see “Installing the Chassis Cover.” 18. Remove the front bezel. For instructions, see “Installing the Front Bezel.” 19. Plug all peripheral devices and the AC power cable back into the server. Removing a Floppy Drive from the Slimline Bay (No Backplane Installed) 1.

  • Page 78: Installing A Floppy Drive Into The Converted Hard Drive Bay (Backplane Installed)

    Installing a Floppy Drive into the Converted Hard Drive Bay (Backplane Installed) The floppy drive conversion kit can only be installed into a system that is using either the SATA or the SCSI backplane. The floppy drive conversion kit must be installed in the left, top hard drive bay, directly under the slimline drive bay.

  • Page 79: Figure 47. Inserting A Floppy Drive Into The Floppy Drive Conversion Kit Carrier

    Hardware Installations and Uprades 7. Slide the floppy drive into the drive carrier, rear of the drive first, with the underside of the drive facing down. 8. Line up the holes in the side of the drive with the holes in the carrier. See letter “A” in the figure below.

  • Page 80: Figure 49. Installing The Rails Onto The Floppy Drive Conversion Kit Carrier

    10. Reattach the slide rails onto floppy drive conversion kit carrier. See the figure below. TP01309 Figure 49. Installing the Rails onto the Floppy Drive Conversion Kit Carrier 11. Open the connector on the rear of the floppy drive by pulling up on the connector cover. See letter “A”...

  • Page 81: Figure 51. Installing The Floppy Drive Into The Chassis

    Hardware Installations and Uprades 14. Slide the carrier assembly into the upper left hard drive bay until it clicks into place. See letter “A” in the figure below. 15. Open the connector labeled “Floppy Con” on the backplane by pulling up on the connector cover.

  • Page 82: Removing A Floppy Drive From The Converted Hard Drive Bay

    Removing a Floppy Drive from the Converted Hard Drive Bay 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 83: Installing A Dvd-Rom Or Cd-Rom Drive Into Slimline Bay (Backplane Installed)

    (Backplane Installed) NOTE The carrier for the slimline DVD-ROM drive / CD-ROM drive was pre- installed in the slimline drive bay of your Server Chassis SR2400. 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.”...

  • Page 84: Removing A Cd-Rom Or Dvd-Rom Drive From The Slimline Bay (Backplane Installed)84

    10. Slide the DVD-ROM / CD-ROM drive carrier into the chassis. See letter “A” in the figure below. 11. Connect the loose end of the CD-ROM drive cable to the backplane connector. See letter “B” in the figure. For assistance in locating connectors on the SATA backplane, see “Hot-Swap SATA Backplane Connections.”...

  • Page 85: Installing A Dvd-Rom Or Cd-Rom Drive Into Slimline Bay (No Backplane Installed)

    NOTE The carrier for the slimline DVD-ROM drive / CD-ROM drive was pre- installed in the slimline drive bay of your Server Chassis SR2400. The interposer board and floppy drive power adapter cable used in these instructions was sent to you with your fixed drive kit.

  • Page 86: Figure 54. Installing A Dvd-Rom Or Cd-Rom Drive Into The Slimline Carrier

    6. Align the two holes at left edge of DVD-ROM / CD-ROM drive with the cutouts in drive carrier. See letter “A” in the figure below. 7. Lower the right side of the DVD-ROM / CD-ROM drive into the carrier until it clicks into place.

  • Page 87: Figure 55. Installing A Dvd-Rom Or Cd-Rom Drive Into The Chassis

    Hardware Installations and Uprades 9. Insert the DVD-ROM / CD-ROM drive carrier into the chassis. See letter “A” in the figure below. 10. If it is not already connected, connect the 2x3 end of the DVD-ROM/CD-ROM drive power cable that was included with your fixed drive kit to the 2x3 power connector on the SATA power adapter cable.

  • Page 88: Removing A Dvd-Rom Or Cd-Rom Drive From Slimline Bay (No Backplane Installed)88

    Removing a DVD-ROM or CD-ROM Drive from Slimline Bay (No Backplane Installed) 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 89: Installing The Pci Riser Assembly

    Hardware Installations and Uprades 6. Lift up on the two levers on the PCI riser assembly to lift the riser assembly from the chassis. See the figure below. 7. If you need to add or replace a PCI riser connector, see “Installing and Removing a PCI Riser Connector.”...

  • Page 90: Installing And Removing A Pci Riser Connector

    7. Set the riser assembly straight down, matching the hooks in the back of the riser assembly to the notches in the rear of the chassis. See the figure below. 8. Press firmly to push the riser into the slots on the server board. 9.

  • Page 91: Removing A Pci Riser Connector

    Hardware Installations and Uprades Removing a PCI Riser Connector 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3.

  • Page 92: Installing A Pci Riser Connector

    Installing a PCI Riser Connector 1. Observe the safety and ESD precautions at the beginning of this book. See “Safety Information.” 2. Power down the server and unplug all peripheral devices and the AC power cable. 3. Remove the chassis cover. For instructions, see “Removing the Chassis Cover.”...

  • Page 93: Installing And Removing A Pci Add-In Card

    Hardware Installations and Uprades Installing and Removing a PCI Add-in Card In the slots provided by the PCI riser card, you can install either one or two PCI add-in cards. Peripherals and add-in cards are not included in your system and must be purchased separately. The riser connector at the center of the chassis supports a single full-height add-in card or a single low profile PCI add-in card.

  • Page 94: Removing A Pci Add-In Card

    Cover.” Replacing the Control Panel ® The steps for replacing the Standard Control Panel and the Intel Local Control Panel are nearly identical. Use the steps below for both varieties of the control panel. Where necessary, differences between the two control panels are noted.

  • Page 95: Figure 61. Removing The Control Panel From The Chassis

    NOTE The cables at the rear of the control panel are positioned differently for the ® Intel Local Control Panel and the Standard Control Panel. In the Local Control Panel, the USB cable (letter “D” in the figure below) is perpendicular to the front panel cable (letter “C”...

  • Page 96: Replacing A System Fan

    Replacing a System Fan The system fans at the front of the Server Chassis SR2400 can be individually replaced if one of them fails. You must have four fans installed in the back four positions of the fan module. The Server Chassis also allows you to install four redundant fans. The redundant fans must be installed as a set of four and are installed in the four front fan sockets of the fan module.

  • Page 97: Replacing The Power Supply Distribution Module

    Hardware Installations and Uprades Replacing the Power Supply Distribution Module The power supply distribution module is at the front of the power supply. This module can be replaced if it fails. To replace the power supply distribution module, use the following instructions. 1.

  • Page 98: Figure 64. Disconnecting The Power Cables From The Server Board

    8. Unplug the main power, power signal and CPU power cables from the server board. The position of your cables may be different. See your server board documentation to locate the connection points. In the diagram below, letter “A” shows the main power cable, letter “B” shows the power signal cable, and letter “C”...

  • Page 99: Figure 66. Disconnecting The Flex And Power Cables

    Hardware Installations and Uprades 10. (Fixed SATA system only): Disconnect the SATA power adapter cable from the power supply. In the figure below, letter “B” is the connector from the power supply. Letter “A” is the connector from the SATA power adapter cable. TP01351 Figure 66.

  • Page 100: Figure 68. Installing The Power Distribution Module

    13. Set the replacement power supply distribution module into the chassis and slide it backward against the power supply. See letters “A” and “B” in the figure below. 14. Push down on the lever at the front of the power distribution the power supply distribution module while lining up the holes on power supply stands on chassis.

  • Page 101: Installing Or Replacing A Hot-Swap Power Supply

    Hardware Installations and Uprades 23. Install the chassis cover. For instructions, see “Installing the Chassis Cover.” Installing or Replacing a Hot-swap Power Supply The power supply can be replaced if it, or one of the fans integrated into it, fails. If your server uses a redundant power supply, you do not need to power down your server to replace the failed power supply, as long as the remaining power supply is plugged into an AC power source and is functioning.

  • Page 102: Installing Or Removing The Sata Or Scsi Backplane

    3. Slide the new power supply into the opening until it clicks into place. The latch on the rear of the power supply must be at the right. 4. Plug in the AC power cable for the new power supply. Installing or Removing the SATA or SCSI Backplane You received your server chassis with your choice of one of three backplane options: A hot-swap SCSI option that came with a SCSI backplane that came with a flex cable, a SCSI...

  • Page 103: Figure 70. Removing A Sata Or Scsi Backplane

    Hardware Installations and Uprades  If you are converting from a hot-swap system to a fixed drive system, you will need to remove two air baffles. For instructions, see “Removing the Large Hot-swap Air Baffle (Backplane Installed)” and “Removing the Small Hot-swap Air Baffle (Backplane Installed).”...

  • Page 104: Installing A Replacement Sata Or Scsi Backplane

    Installing a Replacement SATA or SCSI Backplane If you are installing a SATA or SCSI backplane for the first time (not installing a replacement backplane), see the installation instructions that came with your backplane. The instructions below assume some of the cables are already installed. 1.

  • Page 105: Figure 71. Installing A Sata Or Scsi Backplane

    Hardware Installations and Uprades TP01074 Figure 71. Installing a SATA or SCSI Backplane 13. Connect the flex cable between the server board and the backplane. See letter “A” in the figure below. See your server board documentation to locate the connection point on the server board. 14.

  • Page 106: Figure 72. Installing A Sata Or Scsi Backplane

    Figure 72. Installing a SATA or SCSI Backplane 16. Install the fan module. For instructions, see “Installing the Fan Module.” 17. Install the air baffle. For instructions, see “Installing the Large Hot-swap Air Baffle (Backplane Installed).” 18. Install the processor air duct. For instructions, see “Installing the Processor Air Duct.”...

  • Page 107: Installing A Tape Drive

    Hardware Installations and Uprades Installing a Tape Drive To install a tape drive into your Server Chassis SR2400, your system must meet the following requirements:  You must purchase the tape drive kit, order number ADRTAPEKIT.  You must purchase a 3.5-inch SCSI tape drive.

  • Page 108: Figure 74. Inserting A Tape Drive Into The Carrier

    6. The sixth drive bay is directly below the tape drive bay in the chassis. Lift the lever at the rear of the hard drive blank that is installed in the sixth drive bay to remove the blank from the chassis.

  • Page 109: Figure 76. Connecting The Tape Drive Cables

    Hardware Installations and Uprades 9. Attach the end of the SCSI cable that is labeled “Tape Drive” to the SCSI connection on the tape drive. 10. Route the SCSI cable along the front of the fan module and then through the front and rear openings on the underside of the air baffle.

  • Page 110: Filling Empty Chassis Bays

    Filling Empty Chassis Bays A filler panel, drive blank, or empty drive carrier must be installed into any empty drive bay. To access the drive bays, install the front bezel if it is installed. For instructions, see “Removing the Front Bezel.”...
  • Page 111 Hardware Installations and Uprades...

  • Page 112: Technical Reference

    Technical Reference Power Supply Specifications 700-W Redundant Power Supply Input Voltages 700-W Power Supply 100-127 V∼ at 50/60 Hz; 8.9 A max. 200-240 V∼ at 50/60 Hz; 4.5 A max. 700-W Single Power Supply Output Voltages 700-W Power Supply The table below lists the total wattage available from the power subsystem for each voltage. If you configure your system heavily, ensure that your loads do not exceed the combined total wattage of 700 Watts.

  • Page 113: System Environmental Specifications

    System Environmental Specifications Table 2. Environmental Specifications Temperature Non-operating –40 ° to 70 °C. Operating 5 ° to 35 °C; derated 0.5 °C for every 1000 ft (305 m) to a maximum of 10,000 ft. Humidity Non-operating 90% relative humidity (non-condensing) at 30 °C. Shock Operating 2.0 g, 11 msec, 1/2 sine...

  • Page 114: Equipment Log And Worksheets

    Processor Speed and Cache Memory Video Display Keyboard Mouse Floppy Drive CD-ROM Drive Tape Drive Hard Disk Drive Hard Disk Drive Hard Disk Drive Hard Disk Drive Hard Disk Drive Hard Disk Drive continued Intel® Server Chassis SR2400 User Guide...
  • Page 115 Equipment Log and Worksheets Equipment Log (continued) Item Manufacturer Name and Model Number Serial Number Date Installed Intel® Management Module Local Control Panel...

  • Page 116: Current Usage

    1st Hard Drive 2nd Hard Drive 3rd Hard Drive Hard Drive Hard Drive Hard Drive Tape Drive Expansion Board 1 Expansion Board 2 Expansion Board 3 Expansion Board 4 Expansion Board 5 Intel® Management Module Standard or Local Control Panel Total Current...
  • Page 117 Equipment Log and Worksheets Worksheet, Total Combined Power Used by the Server 1. From the previous worksheet, enter the total current for each column. 2. Multiply the voltage by the total current to get the total wattage for each voltage level. 3.

  • Page 118: Product Regulatory Compliance

    IRAM Certification (Argentina) GB4943- CNCA Certification (China) Product EMC Compliance – Class A Compliance The Server Chassis SR2400 has been has been tested and verified to comply with the following ® electromagnetic compatibility (EMC) regulations when installed a compatible Intel host system.

  • Page 119: Certifications / Registrations / Declarations

    Regulatory Information and Compliance Certifications / Registrations / Declarations UL Certification (US/Canada) CE Declaration of Conformity (CENELEC Europe) FCC/ICES-003 Class A Attestation (USA/Canada) VCCI Certification (Japan) C-Tick Declaration of Conformity (Australia) MED Declaration of Conformity (New Zealand) BSMI Certification (Taiwan) GOST R Certification / License (Russia) Belarus Certification / License (Belarus) RRL Certification (Korea)

  • Page 120: Electromagnetic Compatibility Notices

    (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. For questions related to the EMC performance of this product, contact: Intel Corporation 5200 N.E. Elam Young Parkway Hillsboro, OR 97124...

  • Page 121: Industry Canada (Ices-003)

    Regulatory Information and Compliance This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 122: Vcci (Japan)

    English translation of the notice above: 1. Type of Equipment (Model Name): On License and Product 2. Certification No.: On RRL certificate. Obtain certificate from local Intel representative 3. Name of Certification Recipient: Intel Corporation 4. Date of Manufacturer: Refer to date code on product...

  • Page 123: Regulated Specified Components

    URL: http://channel.intel.com/go/serverbuilder If you do not have access to Intel’s Web address, please contact your local Intel representative. Server Chassis (base chassis is provided with power supply and fans)UL listed. Server boardyou must use an Intel server board—UL recognized.

  • Page 124: Getting Help

    Telephone All calls are billed US $25.00 per incident, levied in local currency at the applicable credit card exchange rate plus applicable taxes. (Intel reserves the right to change the pricing for telephone support at any time without notice). Before calling, fill out the “Issue Report Form” on the following pages.
  • Page 125 SA at 800 800 311. Once connected, dial 800 843 4481 Chile (Mainland and Juan) Contact AT&T USA at 800 225 288. Once connected, dial 800 843 4481 Miami 1 800 621 8423 For an updated support contact list, see http://www.intel.com/support/9089.htm/...

  • Page 126: Intel Server Issue Report Form

    Server Issue Report Form Date Submitted: Company Name: Contact Name: Email Address: Intel Server Product: Priority (Critical, Hot, High, Low): Brief Problem Description. Provide a brief description below. See the last page for space to include a detailed problem description.
  • Page 127 Intel® Server Issue Report Form Operating System Information Operating System Version Service Pack # Peripheral Information Check each box below that is used, and provide the requested information Peripheral Card or Peripheral Description Driver IRQ # I/O Base FW Rev#...
  • Page 128 Complete Problem Description In the space below, provide a complete description of the steps used to reproduce the problem or a complete description of where the problem can be found. Please also include any details on troubleshooting already done.
  • Page 129 Intel® Server Issue Report Form...

  • Page 130: Warranty

    Product or to refund the then-current value of the Product. In no event will Intel be liable for any other costs associated with the replacement or repair of Product, including labor, installation or other costs incurred by buyer and in particular, any costs relating to the removal or replacement of any product soldered or otherwise permanently affixed to any printed circuit board.

  • Page 131: Warranty Limitations And Exclusions

    Limitations of Liability Intel’s responsibility under this, or any other warranty, implied or expressed, is limited to repair, replacement, or refund, as set forth above. These remedies are the sole and exclusive remedies for any breach of warranty.

  • Page 132: How To Obtain Warranty Service

    How to Obtain Warranty Service To obtain warranty service for this Product, you may contact Intel or your authorized distributor. North America and Latin AmericaTo obtain warranty repair for the product, please go to the following Web site to obtain instructions: http://support.intel.com/support/motherboards/draform.htm...

Table of Contents
