Server Chassis Features
Hot-Swap SATA Backplane Connections
The diagram below shows the connection points on the rear of the SATA backplane. The power
supply, server board and a SATA RAID card can be connected to the locations below.
A. OPT connector
B. Location for sixth drive board (accessory)
C. Fan distribution cable connector
D. Flex cable connector
E. SATA channel D connector
Hot-Swap SCSI Backplane Connections
The diagram below shows the connection points on the rear of the SCSI backplane. The power
supply, server board and a SCSI RAID card can be connected to the locations below.
A
A. SCSI connector
B. OPT connector
C. Location for sixth drive board (accessory)
Intel® Server Chassis SR2400/SR2400DC User Guide
A
B
C
J
F. SATA channel B connector
G. SATA channel C connector
H. SATA channel A connector
I. Backplane power connector
J. SATA channel E connector
Figure 3. Rear of SATA Backplane
B
C
D
D. Fan distribution cable connector
E. Flex cable connector
F. Backplane power connector
Figure 4. Rear of SCSI Backplane
E
F
D
G
H
E
I
TP01363
F
TP01364
5
