Page 1 Intel® Entry Storage System SS4200-E User Guide ® A Guide for Technically Qualified Assemblers of Intel Identified Subassemblies/ Products Intel Order Number E20699-002...
Page 2 Intel products are not designed, intended or authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of the Intel product could create a situation where personal injury or death may occur.
Page 3: Safety Information
Safety Information Important Safety Instructions Read all caution and safety statements in this document before performing any of the instructions. See also Intel Server Boards and Server Chassis Safety Information on the ® Intel Server Deployment Toolkit CD and/or at http://support.intel.com/support/ motherboards/server/sb/cs-010770.htm.
Page 4: Warnings
Reinstalling enclosure cover: For proper cooling and airflow, always install the enclosure cover before turning on the storage system. Operating it without the enclosure cover in place can damage system parts. Intel® Entry Storage System SS4200-E User Guide...
Page 5: Preface
Hard drives For information about which accessories, memory, and third-party hardware have been ® tested and can be used with your storage system, and for ordering information for Intel products, see http://support.intel.com/support/motherboards/server/ss4200-e/compat.htm. Additional Information and Software If you need more information about this product or information about the accessories that can be used with this storage system, use the following resources.
Page 6 Tested Hardware and Operating Systems List hard disk drives) and http://support.intel.com/support/motherboards/server/ss4200-e/ operating systems that have been validated by Intel for this product For software to manage Third-party software list your Intel® storage system Intel® Entry Storage System SS4200-E User Guide...
Page 7: Table Of Contents
Planning and Configuring Your Installation ................10 Power Cord Connection .......................10 Grounding Checks ........................10 Operation ........................11 Before You Begin .........................11 Power On ..........................11 Starting the Drives .......................11 Disk Drive Status LEDs ......................11 Intel® Entry Storage System SS4200-E User Guide...
Page 8 Weight ..........................55 AC Power Module (1 250-W Power Supply) ............... 55 Power Cord ......................... 56 Cooling Fan ......................... 56 Environment ........................56 A Regulatory and Compliance Information ............59 Product Regulatory Compliance ..................59 viii Intel® Entry Storage System SS4200-E User Guide...
Page 9 End of Life / Product Recycling ....................64 Restriction of Hazardous Substances (RoHS) Compliance ..........64 B Warranty ....................... 65 Limited Warranty for Intel® Chassis Subassembly Products ..........65 Extent of Limited Warranty ....................65 Warranty Limitations and Exclusions ...................66 Limitations of Liability ........................ 66 How to Obtain Warranty Service ....................
Page 10 Advertencias y precauciones sobre seguridad ............... 102 Aplicaciones y usos previstos ....................103 Selección de la ubicación ....................... 103 Manipulación del equipo ......................103 Advertencias el acceso al sistema ..................105 Descarga electrostática (ESD) ....................106 Intel® Entry Storage System SS4200-E User Guide...
Page 11 Table 1. Spare Parts and Accessories ..................8 Table 2. Configuration Requirements..................9 Table 3. Front Panel LED States..................... 12 Table 4. Front Panel Push-button Functionality ..............13 Table 5. Reset/Recovery Functionality during Power-on ............14 Intel® Entry Storage System SS4200-E User Guide...
Page 12 List of Tables Intel® Entry Storage System SS4200-E User Guide...
Page 13 Figure 38. Lifting Left Side of Drive Tray Assembly ..............37 Figure 39. Removing Left Fan Guard..................37 Figure 40. Removing Left Cooling Fan..................38 Figure 41. Installing New Left Cooling Fan ................39 Figure 42. Re-installing Left Fan Guard ................... 40 Intel® Entry Storage System SS4200-E User Guide xiii...
Page 14 Figure 51. Lifting Left Side of Drive Tray Assembly..............47 Figure 52. Locating IDE Connector and Removing DOM ............48 Figure 53. Installing IDE DOM ....................49 Figure 54. Lowering Left Side of Drive Tray Assembly............49 Intel® Entry Storage System SS4200-E User Guide...
Page 15: Storage System Features
(1-in high), 1.5/3.0 Gb/s, 3.5-in form factor SATA disk drives. Each individual drive is field replaceable. ® Figure 1 shows a front view of the Intel Entry Storage System SS4200-E. ® Figure 1. Intel Entry Storage System SS4200-E Enclosure Core Product ®...
Page 16: Figure 2. Rear View
G. Disk Drive 1 Status LED C. Disk Drive 2 Status LED H. Power/Status Push-button D. Disk Drive 3 Status LED I. Disk Drive 4 Status LED E. USB Port 0 Figure 3. Front View Intel® Entry Storage System SS4200-E User Guide...
Page 17: Chassis
System Board Subsystem The system board sub-system consists of: • An Intel® designed system board • A single PCI-e slot intended for debug purposes only Intel® Entry Storage System SS4200-E User Guide...
Page 18: System Board I/O Panel
One RJ-45 port - NIC 1 (1 Gb) • One e-SATA port • Two USB ports: 2 and 3 NIC LEDs Two LEDS at the right and left of the NIC port provide information on NIC status. Intel® Entry Storage System SS4200-E User Guide...
Page 19: System Board Layout
P. SATA 4 Connector G. Front Panel Header Q. SATA 3 Connector H. CPU Power Connector R. SATA 2 Connector I. CPU Processor S. SATA 1 Connector J. Main Power Connector Figure 6. System Board Layout Intel® Entry Storage System SS4200-E User Guide...
Page 20: Front Panel
Important: The Rear Panel is an integral part of the chassis assembly and is not field replaceable. A Rear Panel, consisting of a network connector, a dual e-SATA port and two USB connectors, is present on the rear of the chassis. Intel® Entry Storage System SS4200-E User Guide...
Page 21: Power Supply
See “Front Panel Components” on page 6 for the location of the disk drive status LEDs. See “Front Panel LED States” on page 12 for a description of disk drive status LED states. Intel® Entry Storage System SS4200-E User Guide...
Page 22: Spare Parts And Accessories
Storage System Features Spare Parts and Accessories ® The following replaceable parts are available for the Intel Entry Storage System SS4200- Table 1. Spare Parts and Accessories Part Number Description FXXSS4200EPSU Power supply FXXSS4200EFAN Cooling fan FXXSS4200ESCR RVR (Rotational Vibration Reduction) screw...
Page 23: Getting Started
Getting Started ® In this chapter, you are shown how to setup your Intel Entry Storage System SS4200-E. ® Caution: When connecting up the Intel Entry Storage System SS4200-E, use only the power cord supplied or a power cord which matches the specific voltage and frequency of your country.
Page 24: Enclosure Installation Prerequisites
Preparation of Site and Host Server ® Before beginning, make sure that the site where you intend to set up and use your Intel Entry Storage System SS4200-E has standard AC power available from an independent source or a power distribution unit with a UPS (universal power supply).
Page 25: Operation
Each disk drive has a corresponding status LED on the Front Panel. See “Front Panel LED States” on page 12 for information on illumination states. See “Disk Drive Numbering Convention” on page 9 for positional order of disk drives. Intel® Entry Storage System SS4200-E User Guide...
Page 26: Front Panel Leds And Switches
System is in process of booting up. Amber A critical or non-recoverable condition has occurred. System is off. No power present. Disk Drive Activity Constant blue Activity is present on any disk drive. Intel® Entry Storage System SS4200-E User Guide...
Page 27: Power Down
Press the Power/Status push-button on the Front Panel for less than 3 seconds to perform a graceful shut down, • Press the Power/Status push-button on the Front Panel for greater than 4 seconds to perform a hard shut down. Intel® Entry Storage System SS4200-E User Guide...
Page 28: Reset/Recovery
3. ATA interface On a storage device that is NOT running Microsoft* Windows Home Server software, if pressed, the system will be reset to factory defaults (i.e., IP and password are set to default values). Intel® Entry Storage System SS4200-E User Guide...
Page 29: Hardware Installations And Upgrades
The Intel Entry Storage System SS4200-E ships with no feet installed. You can configure the system for either horizontal or vertical orientation. Note: Feet should be installed for system stability and rotational vibration dampening. Intel® Entry Storage System SS4200-E User Guide...
Page 30: Figure 10. System In Horizontal Configuration
Hardware Installations and Upgrades Figure 10. System in Horizontal Configuration Figure 11. System in Vertical Configuration Intel® Entry Storage System SS4200-E User Guide...
Page 31: Initial Setup
For Vertical Configuration: Remove feet from package. Insert feet into vertical position slots in chassis (see letter “A” in the following figure). Feet are keyed to fit only one way. Figure 13. Orienting Feet for Initial Vertical Configuration Intel® Entry Storage System SS4200-E User Guide...
Page 32: Converting Feet From Horizontal To Vertical Configuration
1. Remove feet from horizontal position slots in chassis (see letter “A” in the following figure) and insert into vertical position slots (see letter “B”). Feet are keyed to fit only one way in slots. Figure 14. Converting Feet from Horizontal to Vertical Configuration Intel® Entry Storage System SS4200-E User Guide...
Page 33: Converting Feet From Vertical To Horizontal Configuration
— Access to power supply unit openings Upon replacement, the cover MUST be secured by tightening the captive screws at the rear of the system. If needed, a Phillips* screwdriver can be used to tighten the screws. Intel® Entry Storage System SS4200-E User Guide...
Page 34: Removing The Enclosure Cover
2. Loosen the two captive screws at the rear of the system (see letter “A” in the following figure). Slide the enclosure cover to the rear (see letter “B”) and then lift upward to remove from the system. Figure 16. Removing Enclosure Cover Intel® Entry Storage System SS4200-E User Guide...
Page 35: Installing The Enclosure Cover
Slide the enclosure cover toward the front of the system (see letter “B”). Secure the enclosure cover to the system by tightening the captive screws at the rear of the system (see letter “C”). Figure 17. Installing Enclosure Cover Intel® Entry Storage System SS4200-E User Guide...
Page 36: Installing A Hard Drive
Note: RVR screws may be removed either prior to lifting the drive retention bracket or after lifting the drive retention bracket. Note: Spare RVR screws are located at the front of the system, inside, by the front panel board. Figure 18. Removing RVR Screws Intel® Entry Storage System SS4200-E User Guide...
Page 37: Figure 19. Unlatching Drive Retention Bracket
Figure 19. Unlatching Drive Retention Bracket 7. Remove new hard drive from packaging. Attach four RVR screws to the hard drive (see letter “A” in the following figure). Figure 20. Attaching RVR Screws to Hard Drive Intel® Entry Storage System SS4200-E User Guide...
Page 38: Figure 21. Installing Hard Drive Into Drive Tray
OR you may first secure the hard drive in the lower drive retention tray, flip the drive assembly over, and then connect the cables. Figure 22. Connect SATA and Power Cables Intel® Entry Storage System SS4200-E User Guide...
Page 39: Replacing A Power Supply
1. Check new power supply for damage. If any damage exists, return power supply to vendor for replacement. 2. Observe all safety and ESD precautions listed in “Safety Information” on page Intel® Entry Storage System SS4200-E User Guide...
Page 40: Figure 24. Lifting Left Side Of Drive Tray Assembly
7. Remove the airflow baffle. This may require compressing the airflow baffle slightly to slide it out of the two chassis tabs at each end of the baffle. Figure 25. Removing Airflow Baffle Intel® Entry Storage System SS4200-E User Guide...
Page 41: Figure 26. Removing Faulty Power Supply
Note: You may need to remove cable ties securing power cables to the middle of the drive tray assembly. Note: Drive tray assembly removed for illustrative purposes. Figure 26. Removing Faulty Power Supply Intel® Entry Storage System SS4200-E User Guide...
Page 42: Figure 27. Removing Retention Tab From Old Power Supply
9. Remove the retention tab from the old power supply (see letter “A” in the following figure). Figure 27. Removing Retention Tab from Old Power Supply 10. Install the retention tab on new power supply. Intel® Entry Storage System SS4200-E User Guide...
Page 43: Figure 28. Installing New Power Supply
“E”). Note: Holes are located in the lower portion of the drive tray assembly for securing cable ties. Note: Drive tray assembly removed for illustrative purposes. Figure 28. Installing New Power Supply Intel® Entry Storage System SS4200-E User Guide...
Page 44: Figure 29. Replacing Airflow Baffle
Figure 30. Lowering Left Side of Drive Tray Assembly 14. Re-install the enclosure cover. For instructions, see “Installing the Enclosure Cover” on page 15. Reconnect all peripheral devices and the AC power cord. Power up the storage system. Intel® Entry Storage System SS4200-E User Guide...
Page 45: Connecting The Power Cord
This product must only be connected to a power source with a safety electrical earth connection. Prior to switching on, ensure that the earth connection has been checked by an electrical engineer qualified in local and national electrical standards. Intel® Entry Storage System SS4200-E User Guide...
Page 46: Replacing A Cooling Fan
3. Turn off all peripheral devices connected to the storage system. Power down the storage system. 4. Disconnect the AC power cord. 5. Remove the enclosure cover. For instructions, see “Removing the Enclosure Cover” on page Intel® Entry Storage System SS4200-E User Guide...
Page 47: Figure 32. Lifting Right Side Of Drive Tray Assembly
7. Remove the two screws securing the fan guard to the rear of the chassis (see letter “A” in the following figure). Remove the fan guard (see letter “B”). Figure 33. Removing Right Fan Guard Intel® Entry Storage System SS4200-E User Guide...
Page 48: Figure 34. Removing Right Cooling Fan From System
Disengage the cooling fan from the rear of chassis by sliding cooling fan upward and out of keyhole slots in the chassis (see letter “B”). Remove the cooling fan from the system (see letter “C”). Figure 34. Removing Right Cooling Fan from System Intel® Entry Storage System SS4200-E User Guide...
Page 49: Figure 35. Installing New Right Cooling Fan
10. Re-install the fan guard (see letter “A” in the following figure). Secure the fan guard to the rear of the chassis with the two screws previously removed (see letter “B”). Figure 36. Re-installing Right Fan Guard Intel® Entry Storage System SS4200-E User Guide...
Page 50: Figure 37. Lowering Right Side Of Drive Tray Assembly
Figure 37. Lowering Right Side of Drive Tray Assembly 12. Re-install the enclosure cover. For instructions, see “Installing the Enclosure Cover” on page 13. Reconnect all peripheral devices and the AC power cord. Power up the storage system. Intel® Entry Storage System SS4200-E User Guide...
Page 51: Figure 38. Lifting Left Side Of Drive Tray Assembly
15. Remove the two screws securing the fan guard to the rear of the chassis (see letter “A” in the following figure). Remove the fan guard (see letter “B”). Figure 39. Removing Left Fan Guard Intel® Entry Storage System SS4200-E User Guide...
Page 52: Figure 40. Removing Left Cooling Fan
Disengage the cooling fan from rear of chassis by sliding the cooling fan upward and out of keyhole slots in chassis (see letter “B”). Remove the cooling fan from the system (see letter “C”). Figure 40. Removing Left Cooling Fan Intel® Entry Storage System SS4200-E User Guide...
Page 53: Figure 41. Installing New Left Cooling Fan
Slide rubber mounting grommets on back of cooling fan into corresponding keyhole slots in chassis (see letter “B”). Connect the fan cable to the system board (see letter “C”). Figure 41. Installing New Left Cooling Fan Intel® Entry Storage System SS4200-E User Guide...
Page 54: Figure 42. Re-Installing Left Fan Guard
Figure 43. Lowering Left Side of Drive Tray Assembly 20. Re-install the enclosure cover. For instructions, see “Installing the Enclosure Cover” on page 21. Reconnect all peripheral devices and the AC power cord. Power up the storage system. Intel® Entry Storage System SS4200-E User Guide...
Page 55: Replacing Memory
4. Remove the enclosure cover. For instructions, see “Removing the Enclosure Cover” on page 5. Lift the right side of the drive tray assembly (see letter “A” in the following figure). Figure 44. Lifting Right Side of Drive Tray Assembly Intel® Entry Storage System SS4200-E User Guide...
Page 56: Figure 45. Locating Dimm Socket And Removing Memory
DIMM socket outward to the open position (see letter “A”). Holding the DIMM by its edges, lift it from the socket (see letter “B”). Store the DIMM in an anti-static package. Figure 45. Locating DIMM Socket and Removing Memory Intel® Entry Storage System SS4200-E User Guide...
Page 57: Figure 46. Installing New Dimm
Figure 47. Lowering Right Side of Drive Tray Assembly 9. Re-install the enclosure cover. For instructions, see “Installing the Enclosure Cover” on page 10. Reconnect all peripheral devices and the AC power cord. Power up the storage system. Intel® Entry Storage System SS4200-E User Guide...
Page 58: Replacing The Cmos Battery
4. Remove the enclosure cover. For instructions, see “Removing the Enclosure Cover” on page 5. Lift the right side of the drive tray assembly (see letter “A” in the following figure). Figure 48. Lifting Right Side of Drive Tray Assembly Intel® Entry Storage System SS4200-E User Guide...
Page 59 9. Being careful to observe the correct polarity, insert the replacement battery into the battery socket. The “+” side of the battery must face the lever side of the battery socket, toward the add-in card slots. Intel® Entry Storage System SS4200-E User Guide...
Page 60: Figure 50. Lowering Right Side Of Drive Tray Assembly
“Installing the Enclosure Cover” on page 12. Reconnect all peripheral devices and the AC power cord. Power up the storage system. 13. Run the BIOS Setup utility to restore the configuration settings to the real-time clock. Intel® Entry Storage System SS4200-E User Guide...
Page 61: Boot Drive
Entry Storage System SS4200-E has two options for loading operating systems or storage software. If the system is running an Intel storage management stack, it will contain an IDE DOM (disk on module) on the system board. This DOM contains the operating system and any management software.
Page 62: Figure 52. Locating Ide Connector And Removing Dom
Ensure the latches are closed enough for easy removal of the IDE DOM otherwise the housing on the IDE connector may be damaged. Disconnect the power cable from the IDE DOM (see letter “B”). Figure 52. Locating IDE Connector and Removing DOM Intel® Entry Storage System SS4200-E User Guide...
Page 63: Figure 53. Installing Ide Dom
Figure 54. Lowering Left Side of Drive Tray Assembly 9. Re-install the enclosure cover. For instructions, see “Installing the Enclosure Cover” on page 10. Reconnect all peripheral devices and the AC power cord. Power up the storage system. Intel® Entry Storage System SS4200-E User Guide...
Page 64 Hardware Installations and Upgrades Intel® Entry Storage System SS4200-E User Guide...
Page 65: Troubleshooting And Problem Solving
Cords are too short Computer Doesn’t Recognize the Subsystem ® 1. Check that the interface cables from the Intel Entry Storage System SS4200-E to the host computer or network equipment are fitted correctly. 2. Check that the LEDs on all installed drives are illuminated blue.
Page 66: Front Panel
3. Check for excessive re-circulation of temperature rise. ambient temperatures in the heated air from rear to front. Reduce local environment and may NOTE: This is not a fault the ambient temperature. be perfectly normal. condition. Intel® Entry Storage System SS4200-E User Guide...
Page 67: Disk Drive Status Faults
When the cover is replaced it MUST be secured by tightening the two captive screws at the rear of the chassis. A Phillips* screwdriver may be used to tighten the captive screws. Intel® Entry Storage System SS4200-E User Guide...
Page 68 Troubleshooting and Problem Solving Intel® Entry Storage System SS4200-E User Guide...
Page 69: Technical Specifications
Meets EN61000-3-2 Output +5 V aux: 4 A; +12 V: 70 A max Output Rails Dimensions 40.5 mm high x 81.5 mm wide x 150 mm long (1.6 in x 3.2 in x 5.9 Intel® Entry Storage System SS4200-E User Guide...
Page 70: Power Cord
PWM Speed Control Individual tacho outputs for each fan Environment Temperature Relative Humidity Max. Wet Bulb Range Operational 10°C to 35°C 20% to 80% 23°C non-condensing Non-Operational 1°C to +50°C 8% to 80% 27°C non-condensing Intel® Entry Storage System SS4200-E User Guide...
Page 71 20g 10ms 1/2 sine (test with drives) 30g 10ms 1/2 sine (test without drives) Shock, Unpackaged Tested to 30-inch drop based on weight of 25G Vibration, Packaged 2.2grms Random 5-500 Hz Vibration, Unpackaged 1.09grms Random 5-500 Hz Intel® Entry Storage System SS4200-E User Guide...
Page 72 Technical Specifications Intel® Entry Storage System SS4200-E User Guide...
Page 73: A Regulatory And Compliance Information
EMC testing. The final configuration of your end system product may require additional EMC compliance testing. For more information, please contact your local Intel representative. This is an FCC Class B device.
Page 74: Product Emc Compliance - Class B Compliance
C-Tick Declaration of Conformity (Australia) • MED Declaration of Conformity (New Zealand) • BSMI Certification (Taiwan) • GOST R Certification / License (Russia) • Belarus Certification / License (Belarus) • RRL Certification (Korea) • IRAM Certification (Argentina) Intel® Entry Storage System SS4200-E User Guide...
Page 75: Product Regulatory Compliance Markings
EMC Marking (Class B) Canada CANADA ICES-003 CLASS B CANADA NMB-003 CLASSE B C-Tick Mark Australia/New Zealand VCCI Marking (Class B) Japan BSMI Certification Taiwan GOST R Marking Russia RRL MIC Mark Korea Intel® Entry Storage System SS4200-E User Guide...
Page 76: Electromagnetic Compatibility Notices
Any changes or modifications not expressly approved by the grantee of this device could void the user's authority to operate the equipment. The customer is responsible for ensuring compliance of the modified product. Intel® Entry Storage System SS4200-E User Guide...
Page 77: Ices-003 (Canada)
Directive (73/23/EEC) and EMC Directive (89/336/EEC). The product has been marked with the CE Mark to illustrate its compliance. VCCI (Japan) BSMI (Taiwan) The BSMI Certification Marking and EMC warning is located on the outside rear area of the product. Intel® Entry Storage System SS4200-E User Guide...
Page 78: Rrl (Korea)
/ or take back. Restriction of Hazardous Substances (RoHS) Compliance Intel has a system in place to restrict the use of banned substances in accordance with the European Directive 2002/95/EC. Compliance is based on declaration that materials banned in the RoHS Directive are either (1) below all applicable substance threshold limits or (2) an approved/pendng RoHS exemption applies.
Page 79: B Warranty
“as is” unless specifically provided for otherwise in any software license accompanying the software. If any Product furnished by Intel which is the subject of this Limited Warranty fails during the warranty period for reasons covered by this Limited Warranty, Intel, at its option, will: •...
Page 80: Warranty Limitations And Exclusions
Limitations of Liability Intel's responsibility under this, or any other warranty, implied or expressed, is limited to repair, replacement, or refund, as set forth above. These remedies are the sole and exclusive remedies for any breach of warranty.
Page 81: Telephone Support
Telephone Support If you cannot find the information you need on Intel's World Wide Web site (http:// www.intel.com/), call your local distributor or an Intel Customer Support representative.
Page 82 Warranty Intel® Entry Storage System SS4200-E User Guide...
Page 83: C Getting Help
Telephone All calls are billed US $25.00 per incident, levied in local currency at the applicable credit card exchange rate plus applicable taxes. (Intel reserves the right to change the pricing for telephone support at any time without notice). For an updated support contact list, see http://www.intel.com/support/9089.htm/...
Page 84: In Asia-Pacific Region
Easter Island....Contact AT&T USA at 800 800 311. Once connected, dial 800 843 4481 Mainland and Juan .. Contact AT&T USA at 800 225 288. Once connected, dial 800 843 4481 Intel® Entry Storage System SS4200-E User Guide...
Page 85 Panama..Contact AT&T USA at 00 800 001 0109. Once connected, dial 800 843 4481 Paraguay ... 001 916 377 0114 Peru ... 001 916 377 0114 Uruguay..001 916 377 0114 Venezuela... Contact AT&T USA at 0 800 2255 288. Once connected, dial 800 843 4481 Intel® Entry Storage System SS4200-E User Guide...
Page 86 Getting Help Intel® Entry Storage System SS4200-E User Guide...
Page 87: D Installation/Assembly Safety Instructions
To do this: 1. Unlock and remove the padlock from the back of the system if a padlock has been installed. 2. Remove and save all screws from the covers. 3. Remove the cover(s). Intel® Entry Storage System SS4200-E User Guide...
Page 88 • Provided with a properly grounded wall outlet. • Provided with sufficient space to access the power supply cord(s), because they serve as the product's main power disconnect. Intel® Entry Storage System SS4200-E User Guide...
Page 89: Deutsch
Anschlußkabel von den I/O Anschlüssen oder Ports ab. 5. Tragen Sie ein geerdetes Antistatik Gelenkband, um elektrostatische Ladungen (ESD) über blanke Metallstellen bei der Handhabung der Komponenten zu vermeiden. 6. Schalten Sie das System niemals ohne ordnungsgemäß montiertes Gehäuse ein. Intel® Entry Storage System SS4200-E User Guide...
Page 90 Schutzhandschuhe tragen. Bei falschem Einsetzen einer neuen Batterie besteht Explosionsgefahr. Die Batterie darf nur durch denselben oder einen entsprechenden, vom Hersteller empfohlenen Batterietyp ersetzt werden. Entsorgen Sie verbrauchte Batterien den Anweisungen des Herstellers entsprechend. Intel® Entry Storage System SS4200-E User Guide...
Page 91 Telekommunikationsleitungen mit dem Modem bestehen; • "mit einer geerdeten Wechselstromsteckdose ausgerüstet sein; • "über ausreichend Platz verfügen, um Zugang zu den Netzkabeln zu gewährleisten, da der Stromanschluß des Produkts hauptsächlich über die Kabel unterbrochen wird Intel® Entry Storage System SS4200-E User Guide...
Page 92: Français
Procédez comme suit: 1. Si un cadenas a été installé sur à l'arrière du système, déverrouillez-le et retirez-le. 2. Retirez toutes les vis des panneaux et mettez-les dans un endroit sûr. 3. Retirez les panneaux. Intel® Entry Storage System SS4200-E User Guide...
Page 93 • "Muni d'une prise murale correctement mise à la terre. • "Suffisamment spacieux pour vous permettre d'accéder aux câbles d'alimentation (ceux-ci étant le seul moyen de mettre le système hors tension). Intel® Entry Storage System SS4200-E User Guide...
Page 94: Español
Para ello: 1. Desbloquee y extraiga el bloqueo de seguridad de la parte posterior del sistema, si se ha instalado uno. 2. Extraiga y guarde todos los tornillos de las tapas.Extraiga las tapas. Intel® Entry Storage System SS4200-E User Guide...
Page 95 • "Provisto de una toma de tierra correctamente instalada. • "Provisto de espacio suficiente como para acceder a los cables de alimentación, ya que éstos hacen de medio principal de desconexión del sistema. Intel® Entry Storage System SS4200-E User Guide...
Page 96: Italiano
1. Aprire e rimuovere il lucchetto dal retro del sistema qualora ve ne fosse uno installato. 2. Togliere e mettere in un posto sicuro tutte le viti delle coperture. 3. Togliere le coperture. Intel® Entry Storage System SS4200-E User Guide...
Page 97 • "Dotata di una presa a muro correttamente installata. • "Dotata di spazio sufficiente ad accedere ai cavi di alimentazione, i quali rappresentano il mezzo principale di scollegamento del sistema. Intel® Entry Storage System SS4200-E User Guide...
Page 98 Installation/Assembly Safety Instructions Intel® Entry Storage System SS4200-E User Guide...
Page 99: E Safety Information
English Safety Information This document applies to Intel® server boards, Intel® server chassis (pedestal and rack- mount), Intel® storage systems and installed peripherals. To reduce the risk of bodily injury, electrical shock, fire, and equipment damage, read this document and observe all ®...
Page 100: Intended Application Uses
To remove power from system, you must unplug the AC power cord from the wall outlet. Your system may use more than one AC power cord. Make sure all AC power cords are Intel® Entry Storage System SS4200-E User Guide...
Page 101: System Access Warnings
Turn off all peripheral devices connected to this product. • Turn off the system by pressing the power button to off. • Disconnect the AC power by unplugging all AC power cords from the system or wall outlet. Intel® Entry Storage System SS4200-E User Guide...
Page 102: Rack Mount Warnings
Always handle boards carefully. They can be extremely sensitive to ESD. Hold boards only by their edges. After removing a board from its protective wrapper or from the server, place the board component side up on a grounded, static free surface. Use a Intel® Entry Storage System SS4200-E User Guide...
Page 103: Other Hazards
Caution: To avoid risk of radiation exposure and/or personal injury: • Do not open the enclosure of any laser peripheral or device • Laser peripherals or devices have are not user serviceable • Return to manufacturer for servicing Intel® Entry Storage System SS4200-E User Guide...
Page 104: Deutsch
Safety Information Deutsch Sicherheitshinweise für den Server Das vorliegende Dokument bezieht sich auf Intel® Serverplatinen, Intel® Servergehäuse (Standfuß und Rack) sowie installierte Peripheriegeräte. Es enthält Warnungen und Vorsichtsmaßnahmen zur Vermeidung von Gefahren durch Verletzung, Stromschlag, Feuer und Beschädigungen von Geräten. Lesen Sie diese Dokument daher sorgfältig, bevor Sie Ihr Intel®...
Page 105: Zielbenutzer Der Anwendung
Verwenden Sie mechanische oder andere geeignete Hilfsmittel zum Transportieren oder Anheben von Geräten. • Entfernen Sie alle Komponenten, die sich leicht abnehmen lassen, um das Gewicht zu reduzieren und die Handhabung zu erleichtern. Intel® Entry Storage System SS4200-E User Guide...
Page 106 Typ entspricht. Jedes Netzteil im System muß über ein eigenes Netzkabel angeschlossen werden. Einige Netzteile von Intel Servern verwenden Nullleitersicherungen. Vorsicht ist geboten im Umgang mit Netzteilen, welche Nullleitersicherungen verwenden, um das Risiko eines elektrischen Schlages zu vermeiden Das Netzteil in diesem Produkt enthält keine Teile, die vom Benutzer gewartet werden...
Page 107: Warnhinweise Für Den Systemzugang
Einbauen von Hot-Plug-Komponenten sorgfältig vor, um nicht mit heißen Komponenten in Berührung zu kommen. Vorsicht: Berühren Sie nicht die rotierenden Lüfterflügel, um Verletzungen zu vermeiden. Falls Ihr System mit eine Lüfterabdeckung besitzt, darf es nicht ohne diese Abdeckung betrieben werden. Intel® Entry Storage System SS4200-E User Guide...
Page 108: Elektrostatische Entladungen (Esd)
Ausbau aus dem Server mit der Bauelementseite nach oben auf eine geerdete, statisch entladene Unterlage.Verwenden Sie dazu, sofern verfügbar, eine leitfahige Schaumstoffunterlage, aber niche die Schutzhülle der Platine. Ziehen Sie die Platine nicht über eine Fläche. Intel® Entry Storage System SS4200-E User Guide...
Page 109: Andere Gefahren
• Öffnen Sie keinesfalls das Gehäuse von Laser-Peripheriegeräten oder Laser- Komponenten. • Laser-Peripheriegeräte oder -Komponenten besitzen keine für den Benutzer wartungsbedürftigen Teile. • Schicken Sie das Gerät für Wartungsarbeiten an den Hersteller zurück. Intel® Entry Storage System SS4200-E User Guide...
Page 110: Français
Français Consignes de sécurité sur le serveur Ce document s’applique aux cartes serveur Intel®, au châssis de serveur Intel® (sur pieds et sur rack) et aux périphériques installés. Pour réduire les risques de dommages corporels, d’électrocution, d’incendie et de dommages matériels, lisez ce document et respectez tous les avertissements et précautions mentionnés dans ce guide avant...
Page 111: Domaines D'utilisation Prévus
• Utilisez l’assistance mécanique ou toute autre assistance appropriée lorsque vous déplacez et soulevez le matériel. • Pour réduire le poids en vue de faciliter la manipulation, retirez tout composant amovible. Intel® Entry Storage System SS4200-E User Guide...
Page 112 Vous devez les débrancher avant d’ouvrir le châssis, d’ajouter ou de supprimer un composant non connectable à chaud. Les alimentations de certains serveurs Intel sont munies de doubles fusibles pôle/neutre: veuillez observer les précautions d'usage afin d'éviter tout risque d'eléctrocution.
Page 113 Attention: Pour éviter de vous blesser, ne touchez pas les pales de ventilateur en mouvement. Si votre système est fourni avec une protection sur le ventilateur, ne mettez pas le système en route sans la protection en place. Intel® Entry Storage System SS4200-E User Guide...
Page 114: Décharges Électrostatiques (Esd)
Utilisez si possible un tapi de mousse conducteru, mais pas l’emballage de la carte. Veillez à ce que la carte ne glisse sur aucune surface. Intel® Entry Storage System SS4200-E User Guide...
Page 115: Autres Risques
Attention: Pour éviter tout risque d’exposition aux rayonnements et/ou de dommage personnel: • N’ouvrez pas l’enceinte d’un périphérique laser. • Les périphériques laser ne sont pas réparables par l’utilisateur. • Retournez-les au fabricant en cas de problème. Intel® Entry Storage System SS4200-E User Guide...
Page 116: Español
Safety Information Español Información de seguridad del servidor ® Este documento se aplica a las tarjetas de servidor de Intel , los gabinetes de servidor de ® Intel (montaje en rack y en pedestal) y los dispositivos periféricos. Para reducir el riesgo de daños corporales, descargas eléctricas, fuego y en el equipo, lea este documento y...
Page 117: Aplicaciones Y Usos Previstos
Utilice medios mecánicos u otros que sean adecuados al trasladar o levantar el equipo. • Para que el peso sea menor para manipularlo con más facilidad, extraiga los componentes que sean de fácil extracción. Intel® Entry Storage System SS4200-E User Guide...
Page 118 CA estén desenchufado antes de abrir le gabinete, agregar o extraer cualquier componente que no es de conexión en funcionamiento. Algunas fuentes de alimentación de electricidad de los servidores de Intel utilizan el polo neutral del fuselaje. Para evitar riesgos de choques eléctricos use precauciones al trabajar con las fuentes de alimentación que utilizan el polo neutral de fuselaje.
Page 119: Advertencias El Acceso Al Sistema
Precaución: Para evitar posibles daños, no toque las aspas en movimiento de los ventiladores. Si el sistema se le ha suministrado con una protección para el ventilador, asegúrese de que cuando esté funcionando el sistema la protección esté en su sitio. Intel® Entry Storage System SS4200-E User Guide...
Page 120: Descarga Electrostática (Esd)
Utilice una almohadilla de espuma conductora si dispone de ella, pero nunca el envoltorio de la tarjeta. No deslice la tarjeta sobre ninguna superficie. Intel® Entry Storage System SS4200-E User Guide...
Page 121 Precaución: Para evitar el riesgo de la exposición a radiaciones o de daños personales: • No abra la caja de ningún periférico o dispositivo láser • Los periféricos o dispositivos láser no pueden ser reparados por el usuario • Haga que el fabricante los repare. Intel® Entry Storage System SS4200-E User Guide...
Page 122 表示如果无视此 “ ? ? ? 项 ” ? ? ? ? ? ? ? 轻微人身伤害或财产损失的危险。警告表示如果无视此 “ ? ? ” ? ? ? ? ? ? ? 严重人身伤害的危险。表示如果无视所示信息，即存在潜在的危险。表示如果不遵守安全指导，存在可导致严重伤害或死亡的电击危险。表示灼热组件或表面。表示请勿触摸风机叶片，否则可能致伤。表示拔下所有交流电线，断开交流电源 Intel® Entry Storage System SS4200-E User Guide...
Page 123 • 远离振动源或物理震动。 • 与电气设备产生的强大电磁场隔离。 • 在易受闪电袭击的地区，我们建议将系统插入电涌抑制器并在闪电期间断开通信线路与调制解调器之间的连接。 • 提供正确接地的墙壁插座。 • 提供足够的空间，以便拿取电源供应线，因为这是本产品的主要电源断开器。设备操作规范减少人身伤害或设备受损的危险： • 移举设备时遵守当地的职业健康与安全要求。 • 借助机械手段或其他合适的手段移举设备。 • 拆除一切易分离组件，以降低重量并方便操作。电源与电气警告注意事项电源按钮（如待机电源标记所示）并不能完全关闭系统的交流电源，只要系统已接通电源，就存在 5V 待机电源。要从系统切断电源，须从墙壁电源插座中拔下交流电线。您的系统可能不止使用一根交流电线。请确保所有的交流电线都已拔下。打开机箱或增加或去除任何热插拔组件之前，确保交流电线已拔下。若非所需的确切类型，请勿尝试修改或使用交流电线。系统的每个电源供应设备都需要一根单独的交流电线。本产品的电源供应设备包含非用户维修部件。请勿打开电源供应设备。电源供应设备包含非常危险的电压级、电流级和能量级。请与生产商联系维修事宜。替换热插拔电源供应设备时，请先拔下需替换的电源供应设备上的电源线，再将其从服务器上移除。 Intel® Entry Storage System SS4200-E User Guide...
Page 124 ⎯ 电源线须拥有适合插座的安全接地插头或触点。 • 电源线为交流电源的主要断开设备。插座须靠近设备并可随时断开。 • 电源线须插入所提供的拥有合适接地的插座。系统使用警告注意事项为避免人身伤害或财产损失，无论何时检查产品内部，以下安全指导都适用： • 关闭所有与本产品相连的外设。 • 按下电源按钮至关闭状态，关闭系统。 • 从系统或墙壁插座上拔下所有交流电线，断开交流电源。 • 断开与系统相连的所有线缆和通信线路。 • 卸除舱口盖时，保留所有螺钉及其他紧固件。完成产品内部检查之后，请用螺钉或紧固件重新固定舱口盖。 • 请勿打开电源供应设备。电源供应设备内没有可维修部件。请与生产商联系维修事宜. • 增加或替换任何非热插拔组件之前，请关闭服务器电源并断开所有电源线。 • 替换热插拔电源供应设备时，请先拔下需替换的电源供应设备上的电源线，然后再从服务器上移除电源供应设备。注意事项如果服务器一直在运行，任何已安装的处理器和吸热设备都可能很热。除非要增加或移除热插拔组件，否则请待系统冷却后再开盖。为避免在热插拔组件安装过程中接触灼热组件，移除或安装热插拔组件时务须小心。 Intel® Entry Storage System SS4200-E User Guide...
Page 125 Safety Information 注意事项为避免受伤，请勿触摸运转的风机叶片。如果系统的风机上配有防护装置，请勿卸下风机防护装置运行系统。机架固定件警告设备的机架须固定在稳固的支座上，以防从中安装服务器或设备时倒塌。须按照机架生产商提供的安装说明进行安装。从下往上将设备安装在机架上，最重的设备安装在机架的最底层。一次只从机架上安装一件设备。您须负责安装整个机架装置的主要电源断开设备。此主要断开设备须随时可用，且须标明为控制整个装置（而不仅限于服务器）的电源。为避免潜在的电击危险，须对机架及其上所安装的每一件设备实行正确的安全接地。静电放电 (ESD) 注意事项 ESD 会损坏磁盘驱动器、主板及其他部件。我们建议您执行 ESD 工作站的所有步骤。如果没有 ESD 工作站，则采取一些静电放电保护措施，操作部件时，戴上与服务器上的机箱接地或任何未喷漆金属表面连接的防静电腕带。操作主板时始终保持小心。它们可能对 ESD 非常敏感。拿持主板时只接触边缘。从保护包装中或从服务器上取出主板后，请将主板组件侧面朝上放置在无静电的接地表面上。请使用导电泡沫垫（若有），不要使用主板包装。请勿将主板在任何表面上滑动。 Intel® Entry Storage System SS4200-E User Guide...
Page 126 Safety Information 其他危险替换电池注意事项不正确替换电池可能导致爆炸危险。替换电池时，请只使用设备生产商推荐使用的电池。请按当地法规处置电池。请勿对电池充电。请勿拆卸、刺穿或以其他方式损坏电池。冷却和气流注意事项按照说明小心布置线缆，尽量减少气流阻塞和冷却问题。为保证适当的冷却和气流，运行系统时请确保机箱盖已安装。未安装机箱盖即运行系统可能导致系统部件受损。安装机箱盖的步骤如下：首先检查并确保系统内没有遗留的未固定工具或部件。 • 检查线缆、内插板和其他组件已正确安装。 • 按产品说明安装机箱盖。 • 激光外设或激光设备注意事项为避免幅射暴露和 / 或人身伤害：请勿打开任何激光外设或激光设备的外壳 • 激光外设或激光设备为非用户维修设备 • 请与生产商联系维修事宜 Intel® Entry Storage System SS4200-E User Guide...

Intel SS4200-E - Entry Storage System NAS Server User Manual

Safety Information

Preface

Storage System Features

Getting Started

Operation

Hardware Installations and Upgrades

Troubleshooting and Problem Solving

Technical Specifications

A Regulatory and Compliance Information

B Warranty

C Getting Help

D Installation/Assembly Safety Instructions

E Safety Information

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intel SS4200-E - Entry Storage System NAS Server

Summary of Contents for Intel SS4200-E - Entry Storage System NAS Server

Table of Contents
