- Page 1 Intel® Storage Server SSR212MC2 Technical Product Specification Revision 1.2 EPSD Technical Support & Services Group...
- Page 2 Revision History Intel® Storage Server SSR212MC2 TPS Revision History Date Revision Modifications Number April 24, 2007 Release copy. May 23, 2007 Corrected Battery Backup product code, clarified expansion slots, corrected RAID sku product code nomenclature. July 10, 2007 Added AC Power consumption tables to section 2.1.
- Page 3 Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
-
Page 4: Table Of Contents
Table of Contents Intel® Storage Server SSR212MC2 TPS Table of Contents 1. Feature Summary ......................... 1 System Components ....................5 System Board Feature Set ..................8 Serial Attached SCSI (SAS) Host Bus Adapter ............9 Hot Swap Backplane ....................9 Enclosure Management Card ................ - Page 5 6.1.3 Intel Server Board S5000PSL ................30 6.1.3.1 USB Header......................30 6.1.4 Intel® RAID Controller SRCSAS144E ..............30 6.1.4.1 Battery Backup...................... 30 External Rear I/O Panel Connectors ..............31 External Front Panel Connectors................31 7. Regulatory Information ...................... 32 6.1 Product Regulation Requirements..................
- Page 6 Intel® Storage Server SSR212MC2 TPS List of Figures Figure 1. Intel® Storage Server SSR212MC2 ................1 Figure 2. Intel® Storage Server SSR212MC2R Block Diagram ........... 5 Figure 3. Intel® Storage Server SSR212MC2 Block Diagram............6 Figure 4. System Components ..................... 7 Figure 5: Vitesse* VSC410 Block Diagram.................
- Page 7 Intel® Storage Server SSR212MC2 TPS List of Tables List of Tables Table 1: Intel® Storage Server SSR212MC2 Hardware Feature Summary ......... 2 ® Table 2: Intel Server Board S5000PSL features ................. 8 ® Table 3: Intel RAID Controller SRCSAS144E features ............... 9 Table 4: SATA/SAS Hot Swap backplane features ..............
- Page 8 List of Tables Intel® Storage Server SSR212MC2 TPS This page intentionally left blank viii Revision 1.2...
-
Page 9: Feature Summary
This Technical Product Specification provides detailed information about the hardware components of the Intel® Storage Server SSR212MC2. The Intel® Storage Server SSR212MC2 is available in two configuration/sku’s: with or without an Intel® RAID Controller SRCSAS144E (product codes SSR212MC2R and SSR212MC2, ®... -
Page 10: Table 1: Intel® Storage Server Ssr212Mc2 Hardware Feature Summary
® ® sequence) Intel Xeon processors. NOTE: The Intel® Storage Server SSR212MC2 does not ship with processors installed. Please refer to the SSR212MC2 Configuration Guide for a list of supported processors. Expandable to 32 GB maximum. Memory Capacity NOTE: The Intel® Storage Server SSR212MC2 does not ship with memory installed. - Page 11 Chassis includes ten hot-swappable redundant system fans for cooling the hard drives, baseboard and SAS Host Bus Adapter (HBA) card. Power Configuration 850 W continuous, 1+1 redundant power supplies. Intel Storage System SSR212MC2 ships with one 850W power supply Environment Ambient Temperature Operating (system): 10 degrees Celsius to +35 degrees Celsius, with maximum change not to exceed 10 degrees Celsius per hour;...
-
Page 12: System Components
Feature Summary Intel® Storage Server SSR212MC2 System Components A block diagram of the SSR212MC2R sku (with RAID card) is shown below. Figure 2. Intel® Storage Server SSR212MC2R Block Diagram Revision 1.2... -
Page 13: Figure 3. Intel® Storage Server Ssr212Mc2 Block Diagram
High Power +12V +12V Connector 3 x +12V Rails +5V, +3.3V Rails BACK Enclosure Management Card +5V Standby PLANE 4 x PSU Status PWR FAULT Temp Flex Cable Sensor Ops Panel Figure 3. Intel® Storage Server SSR212MC2 Block Diagram Revision 1.2... -
Page 14: Figure 4. System Components
Feature Summary Intel® Storage Server SSR212MC2 The components included with the storage system are diagrammed below. Figure 4. System Components Revision 1.2... -
Page 15: System Board Feature Set
Expansion Slots: Two low profile PCI-X 64-bit slot with up to 100/133-MHz support (bus segment Add-in PCI, PCI- PXA) NOTE: one slot occupied by the BBU, if ordered with an Intel® RAID Controller X*, PCI Express* SRCSAS144E (product code SSR212MC2R). Cards Two low profile PCI Express* x4 slots (bus segments PE1 &... -
Page 16: Serial Attached Scsi (Sas) Host Bus Adapter
Up to 32 devices per controller NOTE: Up to 12 front accessible carrier mounted hard disk drives are supported in the Intel® Storage Server SSR212MC2. The remaining 20 devices may be supported via the external SAS connector & external JBOD. -
Page 17: Enclosure Management Card
Intel® Storage Server SSR212MC2 Feature Summary Feature Description Drive Status LEDs Support for separate drive status LEDs (via pin 11) that are visible at the front of each drive carrier. These LED’s indicate the following: • Green LED – ON, drive spinning, but idle. -
Page 18: Sas Expander
Feature Summary Intel® Storage Server SSR212MC2 Figure 5: Vitesse* VSC410 Block Diagram A PLL is used to generate the internal core clock of 40.0MHz from an external 4.0MHz clock source or crystal. Additional external component are limited to a single SPI Flash memory device and Two-Wire Serial peripherals dedicated to system management functions. -
Page 19: Embedded Processor
Intel® Storage Server SSR212MC2 Feature Summary Figure 6: PMC* PM8388 Block Diagram 1.6.1 Embedded Processor The embedded RISC Processor is a MIPS Technologies* MIPS4K with an EJTAG debugging interface. It supports the SMP protocol and SES and is connected as a virtual port with the device base SAS address. -
Page 20: Expander Port Configuration
Feature Summary Intel® Storage Server SSR212MC2 Optionally, the initialization string can point to an external EEPROM. This EEPROM is used to store initialization parameters that are card-specific, like the SAS Base address. Once read, the parameters from the EEPROM will replace those from Flash memory. -
Page 21: Chassis Dimensions And Weight
Intel® Storage Server SSR212MC2 Feature Summary Chassis Dimensions and Weight Table 6: Chassis Dimensions and Weight Height 87.9 mm 3.46 inches Width (across mounting flange) 483 mm 19.01 inches Width (across body of chassis) 443.4 mm 17.46 inches Depth (from rack posts to rear of PCI bulkhead) 666 mm 26.22 inches... -
Page 22: Back Panel I/O Ports And Features
Feature Summary Intel® Storage Server SSR212MC2 Back Panel I/O Ports and Features The Input/Output (I/O) connectors are integrated to the back panel. The figure below shows the Back Panel I/O ports. Figure 7: Back Panel I/O Ports Revision 1.2... -
Page 23: Front Panel And Hdd Bays
Intel® Storage Server SSR212MC2 Feature Summary Front Panel and HDD Bays Figure 8: Chassis Front and Rear Revision 1.2... -
Page 24: Front/Rear Panel Controls And Indicators
Feature Summary Intel® Storage Server SSR212MC2 1.9.1 Front/Rear Panel Controls and Indicators The front/rear panel controls and indicators are defined below: Table 7: Front/Rear Control Button Functions On/Off Switch Toggles the system power on and off. (front mounted) System Reset Reboots the system. -
Page 25: 1.10 Fan Monitoring
Intel® Storage Server SSR212MC2 Feature Summary 1.10 Fan Monitoring The fans provided in the Storage System SSR212MC2 contain a tachometer signal that can be monitored by enclosure management software. 1.10 Rack and Cabinet Mounting Options The chassis was designed to support cabinets that are 19 in (483 mm) wide by up to 36 in (914 mm) deep, and are compliant to the SSI Server Rack specification and EIA 310-D. -
Page 26: Power Sub-System
Power Sub-System Intel® Storage Server SSR212MC2 Power Sub-System This section provides an overview of the Storage System SSR212MC2 power supply sub- system; the power supply enclosure and the power supply module. NOTE: The Storage System SSR212MC2 ships with one 850 Watt power supply module, mounted in the lower slot. -
Page 27: Hot Swapping Power Modules
Intel® Storage Server SSR212MC2 Power Sub-System Figure 11: Power Supply Module The system can operate with one failed module without loss of performance until the failed module is replaced. The modules can be replaced without powering down or disturbing system operation. -
Page 28: Table 13: Power Supply Led Indicators
Power Sub-System Intel® Storage Server SSR212MC2 2.1.2.1 Power Supply LED Indicator The power supply module provides a single external bi-color LED to indicate the status of the power supply. When AC is applied to the Power Supply Unit (PSU) and standby voltages are available, the LED will blink green. -
Page 29: System Cooling Module
Intel® Storage Server SSR212MC2 System Cooling Module System Cooling Module The Storage System SSR212MC2 includes ten individual fans that collectively make up the cooling module. Each fan can be removed (Hot Swapped) individually for ease of maintenance. The Power Supply Module contains two fans for cooling. -
Page 30: Chassis Bays
Chassis Bays Intel® Storage Server SSR212MC2 Chassis Bays The Storage System SSR212MC2 chassis provides twelve hard drive bays at the front of the chassis. All hard drive bays may be populated with a carrier-mounted 3.5 inch SATA or SAS hard disk drive. -
Page 31: Hard Disk Drive Bays
OS/Application control (i.e., your OS/Application must support hot-swap), or data may be lost. NOTE: All drive bays (1 thru 12) are controlled by the single Intel® RAID Controller SRCSAS144E Table 14: Drive Numbering 1) HDD labels are provided in your Storage System SSR212MC2 shipping container to number the drives 1 thru 12. -
Page 32: Hard Disk Drive Carrier
Chassis Bays Intel® Storage Server SSR212MC2 Figure 14: Hard Disk Drive Bays 4.1.1 Hard Disk Drive Carrier Each hard drive used in the system must be mounted to a drive carrier, making insertion and extraction of the drive from the chassis very simple. Each drive tray has its own dual purpose... -
Page 33: Figure 15: Hard Drive Carrier Assembly
Intel® Storage Server SSR212MC2 Chassis Bays Figure 15: Hard Drive Carrier Assembly Revision 1.2... -
Page 34: Internal Boot Drives (Optional)
Intel® Storage Server SSR212MC2 Internal Boot Drives (optional) Included inside the Intel® Storage Server SSR212MC2 is a dual boot drive enclosure, that includes the cabling to accommodate either one or two optional SAS or SATA drives. One or two 2.5” SAS drives can be mounted in the internal Boot Drive Enclosure, and used to store the Operating System and Applications. -
Page 35: System Interconnection
Intel® Storage Server SSR212MC2 System Interconnection System Interconnection Internal Chassis Cables The following cables are provided: 6.1.1 SAS Expander/SAS HBA SAS Host Connctor: FCI 10045646-002 Header, SAS 4i, 1×32 way, 6.1.1.1 vertical, SMD. Table 15: SAS 4i Host Connector Signal Name Signal Name N.C. -
Page 36: Enclosure Management Card/Backplane
System Interconnection Intel® Storage Server SSR212MC2 6.1.2 Enclosure Management Card/Backplane 6.1.2.1 Power Connectors: 2 × Samtec IPS1-105-01-S-D-RA, Socket, 2×5 way, right angle , PIH Table 16: EM Card PWR_A Connector Signal Name Signal Name +12V5 +12V5 +12V5 Table 17: EM Card PWR_B Connector... -
Page 37: Intel ® Server Board S5000Psl
NOTE: the Boot Drive Enclosure must be removed to access the USB header. 6.1.4 Intel® RAID Controller SRCSAS144E One Battery Backup connector cable that provides connectivity between 6.1.4.1 the Intel® RAID Controller SRCSAS144E and the Battery Backup Unit (BBU) mounted in the PCI Slot 6 position. Revision 1.2... -
Page 38: External Rear I/O Panel Connectors
System Interconnection Intel® Storage Server SSR212MC2 External Rear I/O Panel Connectors The Storage System SSR212MC2 provides an aperture for the rear I/O ports. The following I/O ports available: • Two RJ-45 LAN connectors • One DB-9 Serial Port • One Stacked PS2 port for keyboard & mouse •... -
Page 39: Regulatory Information
7.1.2 Product EMC Compliance – Class A Compliance Note: Legally the product is required to comply with Class A emission requirements as it is intended for a commercial type market place. Intel targets 10db margin to Class A Limits FCC /ICES-003 - Emissions (USA/Canada) Verification CISPR 22 –... -
Page 40: 7.1.3 Certifications / Registrations / Declarations
Regulatory Information Intel® Storage Server SSR212MC2 7.1.3 Certifications / Registrations / Declarations UL Certification (US/Canada) CE Declaration of Conformity (CENELEC Europe) FCC/ICES-003 Class A Attestation (USA/Canada) VCCI Certification (Japan) C-Tick Declaration of Conformity (Australia) MED Declaration of Conformity (New Zealand) -
Page 41: 7.1.5 Product Ecology Requirements
All cords and cables shall contain < 100 ppm of cadmium. Restriction of Hazardous Substances (RoHS) Intel has a system in place to restrict the use of banned substances in accordance with the European Directive 2002/95/EC. Compliance is based on declaration that materials banned in the RoHS Directive are either (1) below all applicable substance threshold limits or (2) an approved/pending RoHS exemption applies. -
Page 42: Environmental Limits
System Cooling Requirement 3600 BTU/hour (at 850W) in British Thermal Units (BTU) per Hour System Environmental Testing ® The system has been tested per the Intel Environmental Standards Handbook, Intel document number 662394-03. These tests include: • Temperature Operating and Non-Operating •... -
Page 43: Environmental Limits
Intel® Storage Server SSR212MC2 Environmental Limits Environmental Limits The following table summarizes environmental limits, both operating and non-operating. Table 21: Operating and Non-Operating Environmental Limits Temperature Specification Non-operating -40 degrees celcius to 70 degrees celcius Operating Temperature 10 degrees celcius to 35 degrees celcius... -
Page 44: Calculated Mtbf
Calculated MTBF Intel® Storage Server SSR212MC2 Calculated MTBF The Mean Time Between Failures (MTBF) for the Storage System SSR212MC2 is calculated at 30,800 hours operating at 35 degrees C. The following table shows the MTBF numbers for individual components within the chassis, and does not include hard disk drives. -
Page 45: Glossary
Intel® Storage Server SSR212MC2 Glossary Glossary Word / Acronym Definition Ampere Alternating Current Australian Communication Authority ACPI Advanced Configuration and Power Interface ANSI American National Standards Institute AT Attachment Decibel Average Baseboard Management Controller British Thermal Units Celsius ® Compact Flash... - Page 46 Glossary Intel® Storage Server SSR212MC2 Integrated Circuit I/O Controller Hub Internet Database Connector Integrated Drive Electronics Intel® Management Module Input/Output iSCSI Internet Protocol Small Computer System Interface Information Technology Equipment Kilo (1.024 x 10 Kilobyte Kilovolt Kilohertz Local Area Network...
- Page 47 Intel® Storage Server SSR212MC2 Glossary SOIC Small Outline Integrated Circuit SRAM Static Random Access Memory Server System Infrastructure TQFP Thin Quad Flat Pack Terabyte UART Universal Asynchronous Receiver Transmitter µF Micro Farad (1 x 10 Farads) µS Micro Second (1 x 10...
