Front Panel LEDs and Switches
The Front Panel LED and push-button states are defined in
Table 3. Front Panel LED States
LED
Power/Status Push-
button LED
Disk Drive Activity
LED
12
A. USB Port 0
C. Disk Drive 2 Status LED
E. USB Port 1
G. Disk Drive 1 Status LED
I. Disk Drive 4 Status LED
Figure 9. Front Panel Components
Color
Constant blue
Power present. System is booted and operational.
Flashing blue
System is in process of booting up.
Amber
A critical or non-recoverable condition has occurred.
Off
System is off. No power present.
Constant blue
Activity is present on any disk drive.
Table
3.
B. Disk Drive Activity LED
D. Disk Drive 3 Status LED
F. NIC Activity LED
H. Power Button
Definition
