Storage System Features
System Board I/O Panel
A. NIC Port (1 Gb)
B. e-SATA Port
Connectors
The following connectors are present on the system board I/O panel:
•
One RJ-45 port - NIC 1 (1 Gb)
•
One e-SATA port
•
Two USB ports: 2 and 3
NIC LEDs
Two LEDS at the right and left of the NIC port provide information on NIC status.
4
Figure 5. System Board I/O Panel Connectors
C. USB Port 2
D. USB Port 3
Intel® Entry Storage System SS4200-E User Guide
