- Page 1 ® Intel Storage System SSR316MJ2 Power Distribution Module (FMJPDB) Installation Guide Order Number: C75952-002...
- Page 2 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
-
Page 3: Important Safety Instructions
010770.htm. Instrucciones de seguridad importantes Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en http://support.intel.com/support/motherboards/server/sb/CS-010770.htm. ® Intel Storage System SSR316MJ2 Power Distribution Module... - Page 4 Avoid injury: Lifting the storage system chassis and attaching it to the rack is a two-person job. If needed, use an appropriate lifting device. A fully ® loaded Intel Storage System SSR316MJ2 weighs approximately 31.8 kg (70 lbs.). CAUTIONS Temperature: The operating temperature of the storage system, when installed in an equipment rack, must not go below 5°...
-
Page 5: Table Of Contents
Figure 12. Installing System Fan Assembly ................19 Figure 13. Attaching System Fan Assembly ................. 20 Figure 14. Connecting System Fan Cables ................21 Figure 15. Seating the Power Supplies................. 22 Figure 16. Installing the Chassis Cover ................23 ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 7: About The Power Distribution Module
Distribution Module is installed into the storage system directly behind the backplane board and the backplane fan assembly, in front of the power supply. ® This document describes how to install the FMJPDB Power Distribution Module into the Intel Storage System SSR316MJ2. Contents ®... -
Page 8: Power Distribution Module Installation Procedures
1. Review the safety information and warnings at the beginning of this guide. 2. Power down your Intel® Storage System Console. See letter “A” in Figure 1. 3. Remove both AC power cords from the AC power inputs at the rear of your storage system. -
Page 9: Un-Seat Power Supplies
2. While pressing the latch, use the handle to pull the power supply out about one inch. See letter “B” in Figure 2. It is not necessary to completely remove the power supply modules from the bays. TP01880 Figure 2. Un-seating the Power Supplies ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 10: Remove Fan Assembly Screws
Use a Number 1 size Phillips* screwdriver to remove the screw on each side of the system. See letter “A” in Figure 3. These screws hold the system fan assembly in place. These screws will be re- installed later. TP01800 Figure 3. Removing System Fan Assembly Screws ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 11: Disconnect Fan Cables
2. Disconnect the Fan 4 cable from the server board. See letter “B” in Figure 4. 3. Disconnect the Fan 5 cable from the server board. See letter “C” in Figure 4. TP01801 Figure 4. Disconnecting System Fan Cables ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 12: Remove Fan Assembly
Simultaneously pull up on both sides of the system fan assembly to remove the fan assembly from the storage system. See letter “A” in Figure 5. TP01885 Figure 5. Removing System Fan Assembly ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 13: Cut Cable Ties And Remove Dimm
3. Lift up on the DIMM to remove it. See letter “C” in Figure 6. Place the DIMM on a static free surface. TP01881 Figure 6. Cutting Cable Ties and Removing DIMM ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 14: Disconnect Power Distribution Module Cables
Disconnect Power Distribution Module Cables Disconnect the two 12-pin power distribution module connectors from the backplane board. See letter “A” in Figure 7. TP01805 Figure 7. Disconnecting Power Distribution Module Cables ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 15: Disconnect Cables And Remove Power Distribution Module
4. Press down on the lever at the front of the power distribution module. While holding the lever down, remove the power distribution module from the system. See letter “D” in Figure 8. Figure 8. Remove Power Distribution Module from System ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 16: Install New Power Distribution Module
3. Insert new plastic cable ties through the two steel links on the side of the chassis. Wrap the plastic cable ties around the power distribution cables and pull the ties tight around the cables. See letter “B” in Figure 9. Figure 9. Installing the Power Distribution Module ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 17: Connect Cables And Install Dimm
6. Push down on the top edge of the DIMM until the retaining clips snap into place. Make sure the clips are firmly in place. See letter “E” in Figure 10. TP01883 Figure 10. Connecting Cables and Installing DIMM ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 18: Connect Power Distribution Module Cables
Connect Power Distribution Module Cables Connect the two 12-pin power distribution module cables to the backplane board. See letter “A” in Figure 11. TP01808 Figure 11. Connecting Power Distribution Module Cables ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 19: Install Fan Assembly
2. Align the holes on the bottom edge of the system fan assembly with the blue plastic shock brackets on the bottom of the chassis. 3. Set the system fan assembly into place. See letter “A” in Figure 12. TP01811 Figure 12. Installing System Fan Assembly ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 20: Attach Fan Assembly
Use a Number 1 size Phillips screwdriver to attach the fan assembly to the chassis, using one screw at each side of the system. See letter “A” in Figure 13. TP01812 Figure 13. Attaching System Fan Assembly ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 21: Connect System Fan Cables
2. Connect the Fan 4 cable to the server board. See letter “B” in Figure 14. 3. Connect the Fan 5 cable to the server board. See letter “C” in Figure 14. TP01813 Figure 14. Connecting System Fan Cables ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 22: Seat Power Supplies
For each power supply, use the power supply handle and squeezable bracket to slide the power supply into position. See letter “A” in Figure 15. TP01884 Figure 15. Seating the Power Supplies ® Intel Storage System SSR316MJ2 Power Distribution Module... -
Page 23: Finishing Up
3. Tighten the two thumb screws at the rear of the chassis. See letter “B” in Figure 16. 4. Connect the AC power cables. See letter “C” in Figure 16. 5. Power on your Intel® Storage System Console. See letter “D” in Figure 16. TP01816 Figure 16.
