Technical Specifications
Power Cord
Important: The plug and the complete power cord assembly must meet the standards appropriate to
the country, and must have safety approvals acceptable in that country.
United States
Must be NRTL Listed (National Recognized Test Laboratory, e.g., UL)
Cord type
Plug
Socket
Europe and Others
General requirements:
Cord type
Socket
Cooling Fan
Fans
Environment
Operational
Non-Operational
56
SV or SVT, 18 AWG minimum, 3 conductor, 4.5 M max length.
NEMA 5-15P grounding-type attachment plug rated 120V 10A
or
IEC 320 C14, 250V, 10A.
IEC 320, C-13, 250V, 10A.
Harmonized, H05-VVF-3G1.0
IEC 320, C-13, 250V, 10A.
Quantity: (2) 70mm x 70mm x 15mm axial
PWM Speed Control
Individual tacho outputs for each fan
Temperature
Range
10°C to 35°C
20% to 80%
non-condensing
1°C to +50°C
8% to 80%
non-condensing
Relative Humidity
Max. Wet Bulb
23°C
27°C
Intel® Entry Storage System SS4200-E User Guide
