Table 3. Front Panel LED States
NIC Activity LED
Disk Drive Status
LED

Table 4. Front Panel Push-button Functionality

Push-button State
On/Off

Power Down

Note: Refer to your storage software documentation for any power down procedures before
powering down the system.
To power down the system, either:
•
Press the Power/Status push-button on the Front Panel for less than 3 seconds to
perform a graceful shut down,
or
•
Press the Power/Status push-button on the Front Panel for greater than 4 seconds to
perform a hard shut down.
Intel® Entry Storage System SS4200-E User Guide
Constant blue Link is active.
Flashing blue Link activity is present.
Constant blue Drive is available
Constant amber Disk drive fault has occurred.
Flashing amber Disk drive is rebuilding.
Off Disk drive is not present.
Function of this button is dependent on the enclosure status.
If system is connected to power source but not operating: Press button
to activate and commence boot process.
If system is operating:
•
Depress push-button for <3 seconds to shut down system gracefully.
•
Depress push-button for >4 seconds to perform a hard shut down of
system.
Definition
Operation
13
