debug ip bgp
default-fields peer
default-fields route
Use to set the baseline on all BGP statistics as the current values.
For example, if you issue the baseline ip bgp command, all the current values
of BGP statistics become the baseline values. If the current value of the Total
message sent parameter is 105, and the value goes up to 120 messages, the new
value is displayed as 15.
Example
host1#baseline ip bgp
There is no no version.
See baseline ip bgp.
Use to display information about BGP logs for inbound or outbound events, or
both.
Example
host1#debug ip bgp
There is no no version, but you can use the undebug ip bgp command to disable
display of information previously enabled with the debug ip bgp command.
See debug ip bgp.
Use to specify fields that are displayed by default by a subsequently issued show
ip bgp summary command.
Use the intro keyword to enable the display of introductory information about
BGP attributes.
The order in which you specify the fields has no effect on the order in which
they are displayed.
Example
host1:pe2(config-router)#default-fields peer remote-as state
messages-received messages-sent up-down-time
host1:pe2#show ip bgp summary
Neighbor AS
State
1.1.1.1
100
Established
Use the no version to remove fields from the output of subsequently issued show
ip bgp summary commands.
See default-fields peer.
Chapter 1: Configuring BGP Routing
Messages
Up/down time
Sent
00:07:55
94
Monitoring BGP
Messages
Received
92
159
